Intelligent DALI lighting in emergency operation
Disable object for suppressing error messages
when the ECG is disconnected during emergency
light testing.
Emergency power supplyStandard power supply
AC 230 V
AC 230 V/DC 220 V
DALI-ECG
DALI-ECG
2
3
1
5
46
• Parameterization of dimming value of DALI-ECG
in emergency operation via KNX/DALI Gateway
• The continued transmission of status messages
in emergency operation is possible because there
is no interruption of supply to KNX and DALI
• The KNX power supply can bridge short power
failures (buffer time approx. 200 ms)
1
Changeover unit
2
KNX line coupler
3
KNX power supply
4
KNX/DALI Gateway
5
Emergency luminaire
6
KNX binary input
