Intelligent DALI lighting in normal mode
Emergency power supplyStandard power supply
AC 230 V
AC 230 V/DC 220 V
DALI-ECG
DALI-ECG
2
3
1
5
46
1
Changeover unit
2
KNX line coupler
3
KNX power supply
4
KNX/DALI Gateway
5
Emergency luminaire
6
KNX binary input
• Lighting control with DALI
• Feedback of fault indications and failure
of lighting and ECGs to building control
