User Manual
All key data at a glance
Switching actuators N 53.D.1
• One relay contact per output as
switching element
• Rated contact operating voltage
AC 230 V
• Rated contact frequency: 50 / 60 Hz
• Per output with mechanical display
of the switching status via slide
switches, which can also be used for
direct manual operation of the
switching output
• Maintenance-free terminals for
connection and through-wiring
of untreated single-core, stranded
or multi-core conductors,
0.5 ... 2.5mm²
• One phase terminal per output
• Bus-powered electronics
• Integrated bus coupling unit, bus
connection via bus terminal
• Red LED for display of the activation
of the addressing mode
as well as the operational readiness
• Housing: plastic, color RAL 7035
(light grey), N-system
• DIN rail mounted device for mount-
ing on rail TH35 according to
DIN EN 60715
• Type of protection: IP 20
• Construction site switching function
• Object for monitoring the device
function
• Object for the specific retrieval
of status values
Control functions
• selectable operating mode
(normal mode, time switch mode,
flashing mode)
• selectable relay mode (NC/NO)
• variable On and Off delay times
• two selectable logic operations
(AND, OR, NAND, NOR, XOR, FILTER,
TRIGGER)
• selectable switching state on bus
voltage failure and selectable start
value of the switching object on
bus voltage recovery
• optional addition of a night mode
object for time-limited switching On
of the output, i.e. the illumination,
at night
Timed functions
• Variable On period at night or time
switch mode
• selectable addition of an object
to change the On period at night
or time switch mode
• selectable post-triggering
(1x, 2x, 3x, 4x, 5x) of the On period
in time switch mode
• Selectable warning signal prior to
imminent switching-off by brief
off and on switching
• Flashing at night or in time switch
mode and/or via an optional warning
object
Override functions
• For manual override ON
• For permanent OFF switching
• Blocking of the output
• For switching on or off
in forced mode
Diagnostic functions
• Counting of operating hours and
threshold monitoring
• Counting of load cycles and
threshold monitoring
• Integrated 8-bit scene control
with up to 8 scenes per output
Common properties Functions per device
Type Product title DT Order no. PU
(Unit, set M)
PS/P
unit
PU Weight per
PU (kg)
Price
N 530D31 Switching actuator 4 x AC 230 V, 6 AX, C-load A 5WG1530-1DB31 1 1 0.235
N 530D51 Switching actuator 8 x AC 230 V, 6 AX, C-load A 5WG1530-1DB51 1 1 0.430
N 530D61 Switching actuator 12 x AC 230 V, 6 AX, C-load A 5WG1530-1DB61 1 1 0.630
N 532D31 Switching actuator 4 x AC 230 V, 10 AX, C-load A 5WG1532-1DB31 1 1 0.235
N 532D51 Switching actuator 8 x AC 230 V, 10 AX, C-load A 5WG1532-1DB51 1 1 0.430
N 532D61 Switching actuator 12 x AC 230 V, 10 AX, C-load A 5WG1532-1DB61 1 1 0.630
N 534D31 Switching actuator 4 x AC 230 V, 16/20 AX,
C-load
A 5WG1534-1DB31 1 1 0.280
N 534D51 Switching actuator 8 x AC 230 V, 16/20 AX,
C-load
A 5WG1534-1DB51 1 1 0.525
N 534D61 Switching actuator 12 x AC 230 V, 16/20 AX,
C-load
A 5WG1534-1DB61 1 1 0.775
