User Manual

Load data
Type
N 530D31 N 530D51 N 530D61 N 532D31 N 532D51 N 532D61 N 534D31 N 534D51 N 534D61
Contact current
Rated current, AC [A] 6 AX 10 AX 16/20 AX
AC3 operation (p.f. = 0.45) [VA] 2300 2500 3680
Maximum switch-on peak current 400 400 600
•t = 150µs [A] 320 320 480
•t = 250µs [A] 200 200 300
•t = 600µs [A]
Contact voltage
Rated voltage, AC [V] 230 230 230
Service life
Mechanical service life
Switching operations in millions
1 1 1
Electrical service life
Switching operations in millions
3) 3) 3)
Power loss
Maximum power loss per device at
rated power [W]
4 8 12 4 8 12 4 8 12
Switching capacities/load types, loads
Resistive load [W] 2300 3680 3680
Minimum switching capacity [V/mA] 12/100 12/100 12/100
DC switching capacity [V/A] 24/10 24/10 24/10
Maximum capacitive load [µF] 70 140 200
Incandescent lamps
Incandescent lamp [W] 2300 3680 3680
Halogen lamp 230 V [W] 2300 3680 3680
LV halogen lamp with conventional
transformer (inductive) [VA]
500 500 2000
T5/T8 fl uorescent lamps
Uncompensated [VA] 1380 2300 3680
Parallel-compensated
(for max. possible C) [W]
1300 1300 2500
DUO circuit [VA] 1380 2300 3680
Compact lamps
Uncompensated [VA] 1380 1600 3680
Parallel corrected
(at max. possible C) [W]
1100 1100 3000
