Hardware features
Type
N 530D31 N 530D51 N 530D61 N 532D31 N 532D51 N 532D61 N 534D31 N 534D51 N 534D61
Housing data
Design N N N N N N N N N
Modular installation devices for mounting
on TH35 EN 60715 mounting rail
        
Dimensions
Width (1 MW = 18 mm) 4 TE 8 TE 12 TE 4 TE 8 TE 12 TE 4 TE 8 TE 12 TE
Display/control elements
Mechanical local operation
        
Mechanical switching position indication
        
Power supply
Bus-powered electronics
        
Bus connection
Integrated bus coupling unit
        
Bus connection via bus terminal
        
Outputs
Load output
Floating relay contacts 4 8 12 4 8 12 4 8 12
Rated contact voltage, AC [V] 230 230 230 230 230 230 230 230 230
Rated contact current
• AX (200 μF) acc. to EN 50428 [AX] 6
1)
6
1)
6
1)
10
2)
10
2)
10
2)
16/20 16/20 16/20
• AC1 (p.f. = 0.8) acc. to EN 50428 [A] 10 10 10 16 16 16 16 16 16
• AC1 (p.f. = 0.8) acc. to EN 50428 [A] 6 6 6 10 10 10 16 16 16
• 24 V DC (resistive load) [A] 6 6 6 10 10 10 10 10 10
AX: Refers to a capacitive fluorescent lamp load. In conjunction with fluorescent lamp loads, the switchable capacitive loads (200 μF, 140 μF,
70 μF or 35 μF) are specified.
Legend:
1)
at 70 μF
2)
at 140 μF
3)
on request
