Comprehensive
automation functions
The switching actuators offer comprehensive
control, override and diagnostic functions;
usable without additional modules or control-
lers, control and monitoring functions, i.e.
in the same device, and via which ETS can be
activated.
Control functions:
On/off switching commands are
available for controlling and
switching lighting and azd motors,
as well as timing, scene and logic
functions.
Lighting such as LEDs, incandes-
cent lamps and fluorescent lamps,
can be switched on and off via
display and control units or by
evaluating sensor data.
Override functions:
User-defined scope to override
lighting and motors by evaluating
sensor data, manual intervention
or by central function.
Diagnostic functions
The switch actuator diagnostic
and analytical functions are used
to check device functions, device
installation, operating hours and
switching cycles.
All diagnostic functions can be
displayed via monitors.
Display and
operation
units
Control value
Control value
Status
Time
function
Manual
override
Test,
Analysis
Logic
module
Blocking
function
Switching
cycles
Day/night
Central
function
Operating
hours
Sensor data
Lighting
Monitoring
