Switching actuators

The new switching actuators, featuring

four, eight and twelve channels each for

6, 10 and 16/20 amperes, can handle

capacitive, inductive and resistive loads.

Stand-out features include maintenance-

free terminals for rapid connection and

simple looping-through of untreated

conductors.

Control, monitoring and

diagnostic functions

The basic function of switching with

status message can be extended by

logical and timer functions via ETS, as

well as override functions such as

manual ON, continuous OFF, or priority

control. The diagnostic functions also

allow monitoring of limit values based

on operating hours elapsed and switch-

ing cycles.

Switching with analog control values

As an alternative to a binary input

value (ON, OFF), for each switching

channel an analog control value, e.g.

temperature, percentage value, power

(W, kW), illuminance (Lux) and integers

can be converted directly into ON/OFF

switching commands.

Reliability and efficiency

Siemens offers established and reliable

building control technology products.

All switching cycles can handle high

inrush currents for capacitive loads up to

16/20 AX, while the device installation

can be checked using display and

operating elements as well as the test

points of the new switching actuators

with commonly used tools.

High-performance

switching actuators

Wide-ranging applications – efficient installation

and set-up – operation for many years

siemens.com/gamma

The worldwide

standard for

home and

building control

Highlights

• Maintenance-free terminals for

time-saving wire installation

• Achieve high flexibility for individual

system solutions with comprehensive

automation functions

• Converting analog input values into

switching commands (ON/OFF)

• Long-lasting and reliable switching of

loads with a high inrush current

• Quick and simple testing of proper

installation with standard tools and the

operating elements of the device itself

Summary of content (8 pages)

PAGE 1
High-performance switching actuators Wide-ranging applications – efficient installation and set-up – operation for many years The worldwide standard for home and building control Switching actuators The new switching actuators, featuring four, eight and twelve channels each for 6, 10 and 16/20 amperes, can handle capacitive, inductive and resistive loads. Stand-out features include maintenancefree terminals for rapid connection and simple looping-through of untreated conductors.
PAGE 2
Typical switching actuator application AC 230 V 6 KNX 2 1 2 2 3 7 4 8 5 In the example illustrated, the new switching actuators (3) are used to switch the background lighting (2) in the room via presence detectors (1) or push-buttons (4). Both workplace lighting and PCs/monitors are supplied with electricity via a switched socket (5) in the floor box and can be switched on and off centrally for energy-efficient operation.
PAGE 3
Comprehensive automation functions The switching actuators offer comprehensive control, override and diagnostic functions; usable without additional modules or controllers, control and monitoring functions, i.e. in the same device, and via which ETS can be activated. Lighting such as LEDs, incandescent lamps and fluorescent lamps, can be switched on and off via display and control units or by evaluating sensor data.
PAGE 4
N 530D31 N 530D51 N 530D61 N 532D31 N 532D51 N 532D61 N 534D31 N 534D51 N 534D61 Hardware features Design N N N N N N N N N Modular installation devices for mounting on TH35 EN 60715 mounting rail          4 TE 8 TE 12 TE 4 TE 8 TE 12 TE 4 TE 8 TE 12 TE Mechanical local operation          Mechanical switching position indication                   Integrated bus coupling unit          Bu
PAGE 5
N 534D61 N 534D51 N 534D31 N 532D61 N 532D51 N 532D31 N 530D61 N 530D51 Type N 530D31 Load data Contact current Rated current, AC [A] 6 AX 10 AX 16/20 AX AC3 operation (p.f. = 0.
PAGE 6
All key data at a glance Common properties Functions per device Switching actuators N 53.D.
PAGE 7
Technical data 5WG1530-1DB.1 5WG1534-1DB.
PAGE 8
Ingenuity for life comes when building technology creates perfect locations. Not too cold, not too warm. Secure at all times. Protected at all times. We leverage knowledge and technology, products, solutions and services to transform places into perfect locations. We create perfect spots that meet users’ needs – covering every facet of life. #CreatingPerfectPlaces siemens.
