User Manual

Technical data
Cabinet information
Material
Stainless steel 1.4301 (AISI 1304), PU sealing; for further information see
datasheet Rittal AE1016600
Protection class
IP55 EN 60529
EC conformity
Electromagnetic compatibility (EMC)
Low voltage (LVD)
2004/108/EC
2006/95/EC
Electromagnetic compatibility
Emission class EN 61326 [2006]
- HPB10.1
- HPB10-TP
Immunity EN 6100-6-2 [2005]
- HBP10.1
- HPB10-TP
Class B, residential environment
Class A, industrial environment
industrial environment
industrial environment
Power
Power consumption
HBP10.1, HBP10-TP
Standard CMT HPB10.1
option touch panel HPB10-TP, additional
option UPS HPB10-UPS, additional
option manageable switch HPB10-MES,
additional
option KVM extender HPB10-KVM,
additional
inside cabinet
Local unit
230 V, 50 Hz
max. 580 VA
max. 95 VA
max. 500 VA
max. 3 VA
max. 5 VA
max. 5 VA
Ambient conditions
external ambient air temperature
enclosure ambient air temperature
enclosure ambient air humidity
0°C to 40°C
0°C to 45°C
10%
r.h. to 90% r.h., non
condensing
Key lock system
The control panel is equipped with a special key-locking system
Weight
Standard CMT HPB10.1
(including all components)
option touch panel HPB10-TP, additional
option UPS HPB10-UPS, additional
option extender HPB10-KVM, additional
69.0 kg
10.2 kg
9.1 kg
0.4 kg
Fan and filter
Fan
Model: 3325.107
Filter
Fine filter mat, model 3182.100
Software Installed software on the CMT:
Microsoft Windows® Server 2008R2 64bit
Microsoft SQL® Server 2008 and Microsoft SQL® Express 2012
Desigo Insight V5.1 SP2
InfoCenter Suite® 1.6.5 SP1
Adobe Acrobat reader 11.0.03
