User Manual

Lamp indicators
Function
green light yellow light red light
Normal operating



Warning low and high limit of the sensors, door open - occurs



Warning low and high limit of the sensors, door open -
acknowledge



Warning disappears, door contact closed --> normal operating



Alarm low and high limit of the sensors - occurs



Alarm low and high limit of the sensors - acknowledge



Alarm disappears and reset carried out --> normal operating



PX automation station and or TX-IO module damaged



Warning x days before calibration



Warning when calibration is due



Behavior after voltage failure, Microbox switched off /
Additionally, door is opened



Alarm, warning and door open may be present at the same time
-
 continuous light
-
 flashing light
-
 light off
Commissioning
Only authorized personnel are permitted to commission and open the CMT
cabinet.
In order to prevent equipment damage and/or personal injury, always follow local safety
regulations and the required safety standards.
For further information, see the CMT manual and the wiring diagram.
Maintenance
Only authorized personnel are permitted to perform a maintenance tasks.
Always separate the CMT cabinet from the mains before performing any
maintenance tasks.
Warning!
Also after power disconnection it is possible to have separate source voltage at
the terminals =1.16-X4.1 and 2
STOP
Caution!

