User Manual

Special alarms
General alarms like sensor fault, short circuits and open door
Communication BACnet / IP
Communication is via Ethernet with the international standard BACnet protocol.
Capacity
Internal hard disk
160 GB SSD
External hard disk >100 GB
The hardware is designed to allow for a minimum of 3 months of data logging in
the databases. Data logging from:
36 sensors at 1-minute intervals
Memory check
Monitoring and alarming
Monitoring interval: 2 minute
Critical if below: 20 MB
Warning if below: 100 MB
Threshold limit: 2 MB
Optional extension modules
Option related to security:
• Alarm routing via pager, SMS, Fax, File and/ or email
• Uninterrupted power supply (UPS) – HPB10-UPS
• 5 port manageable Ethernet switch – HPB10-MES
Options related to the accessibility:
• Remote Desktop access
• WEB Operation via Internet Explorer
• Integration into the existing network
• Touch panel local operation – HPB10-TP
• Remote screen, keyboard and mouse for operation – HPB10-KVM
• Additional printer on the network
• Additional printer locally via USB
• Additional users
Options related to the usability
• Remote reporting with InfoCenter clients
• Additional customized reports
• Additional customized graphics
• Additional parameters
• Calibration management
Options related to compliance issues
• Integration of the particle counters to comply with Annex 1 of the EU GMP, e.g.
PMS Airnet®, or Climet© using ModBus/IP or 4-20mA
• Standard design documents (URS, FS, SDS, CMP, FAT)
• Standard Verification check or customized to your project
• Execution of Verification check
• Standard Operating Procedures (SOP)
• Options related to system expansion
• Additional I/O modules in the main CMT panel (HPB10.1)
• Remote panel with additional I/Os connected to main panel (CMTE.001)
• Remote autonomous panel with PXC controller and I/O modules (CMTE.002)
