User Manual

Plant Viewer
Measured values, setpoints, operating modes and alarms are displayed on the
screen in real-time and updated continuously
Changes are indicated by the object symbol or by the movement, color, shape or
text of the values affected
Alarm Viewer
Display the associated alarm property sheet with detailed data point information
View, acknowledge, and reset single or multiple alarms
Object-oriented navigation to other application such as Plant Viewer and Log
Viewer
Log Viewer (= Audit trail)
Log Viewer provides users with access to all events that have occurred within the
system. Following event logs are reported:
- Alarms from the process level
- System events from the management level (Desigo Insight) and PX
automation station
- User events such as authorized and unauthorized user log-in
procedures, modification of values, parameters and setpoints
Object Viewer
This Viewer helps users to navigate efficiently through the entire structure. Each
point and parameter can be easily accessed and viewed.
Report
Reporting is done with the InfoCenter software.
Reports can contain system activity as well as trend and alarm data
The InfoCenter has the following table and chart report objects for data analysis:
Table objects
Chart objects
Point Value
Statistics
System Activity
System Activity Summary
Annotation Summary
Alarm Summary
MKT
Scatter
Comparison
Bar
Column
Histogram
Pie
Electronic signature
functionality
Electronic signatures are only used with the PDF reports
generated by
InfoCenter Suite®. In order to sign the PDF reports Adobe Acrobat 6.0 or later is
used. For more information refer to the guideline for use of Digital Signatures in
InfoCenter (149-202EN_EU).
Alarm functionality
Number of alarm sets
max. 4 pro data point
Types of alarm
High alarms
High warnings
Low warnings
Low alarms
Alarm time delay
1 – 3600 s
Alarm visualization
Alarms are visualized on the screen and on the lamps (red and yellow)
