Data Sheet for Product

Housing protection Protection standard
Protection class
IP 30 to EN 60529
III to IEC1140
conformity Meets the requirements of EMC Directive 89/336/EEC
UL/CUL approval UL/CUL 916
Dimensions Orientation during operation Horizontal only
See also dimension diagrams 137 x 172 x 245 mm (H x W x D)
Color Plastic components Gray
Weight excluding packaging Magnetic card encoders
Power supply unit
Serial interface cable
2 230 g
415 g
140 g
Weight including packaging 3 325 g
Connection diagrams
1
2
3
4
5
6
7
8
9
3
2
7
6239Z02
9-pin male connector to
25-pin female connector
2 BUS RS 232 RXD
3 BUS RS 232 TXD
5 GND
Pin layout for
connecting cable
Dimensions
230 14,5
6239M01
30
137
172
6239M02
1500
1500 71100
144
Power supply unit
Dimensions in mm
4/4
Siemens HBC1.M – Magnetic card encoder CM2N6339en
© 2005-2008 Siemens Switzerland Ltd. Sub
j
ect to chan
ge
Building Technologies 31.07.2008
