User Manual

Equipment combinations
Compatibility of other devices
Device HRC3.1 HRC3.2
Type Description Data sheet
Operator units
QAX84.1/PPS2 Flush-mounted room unit with temperature sensor, setpoint
adjustment, Auto/Fan speed button, and LCD display
N1649 X
Actuators
SSB81 Electro-motoric actuator, 200 N, 5.5 mm, AC 24 V, 3P N4891 X X
SSP81 Electro-motoric actuator, 160 N, 2,5 mm, AC 24 V, 3P N4864 X X
STP72E Electro-thermic actuator, 105 N, AC/DC 24 V, 2P N4876 X X
STA72E Electro-thermic actuator, 105 N, AC/DC 24 V, 2P N4875 X X
Valves
VXP45.10-1.6 Three-port valve, external thread, PN16, DN15, kvs 1,6 N4845 X X
VXP47.10-1.6 Three-port valve, external thread, PN16, DN10, kvs 1,6 N4847 X X
VDN2.. Throughport radiator valve, NF, 2-pipe system, PN10 N2106 X X
VPD.. Throughport radiator valve, DIN / NF, pressure-
compensated
N2185 X X
Application Actuator Valve Price / Performance
relationship
Product No. Voltage/
Signal
Type Product No. Type Price
(Index)
Perfor-
mance
Fan coil SSB81 AC 24 V/
3P
Motoric VXP45.10-1.6 3-port equal percentage (high
hydraulic performance)
1.00 High
Cooling or
heating
SSP81 AC 24 V/
3P
Motoric VXP47.10-1.6 3-port linear 0.97 Standard
With 3-port
valves
STP72E AC 24 V/
PWM, 2P
Thermal VXP47.10-1.6 3-port linear 0.63 Medium
Radiator STA72E AC 24 V/
PWM, 2P
Thermal VDN2.. Throughport NF (Norm Francais) 0.38 Standard
STA72E AC 24 V/
PWM, 2P
Thermal VPD.. Throughport NF (Norm Francais)
High performance MiniCombi valve
0.70 High
4/4
