Installation Instructions

Article no. - without filter
Article no. - with filter
6SL3210-1NE22-6UG1
6SL3210-1NE22-6AG1
6SL3210-1NE23-2UG1
6SL3210-1NE23-2AG1
6SL3210-1NE23-8UG1
6SL3210-1NE23-8AG1
Fuse according to IEC / UL
Fuse according to UL, Class J
3NE1803-0
35 A
3NE1817-0
45 A
3NE1817-0
50 A
Power loss 0.3 kW 0.35 kW 0.45 kW
Required cooling air flow 18.5 l/s 18.5 l/s 18.5 l/s
Weight without filter 4.5 kg 4.5 kg 4.5 kg
Weight with filter 5.1 kg 5.1 kg 5.1 kg
Table 7-9 PM230, PT, frame size C, 3 AC 380 V … 480 V
Article no. - without filter
Article no. - with filter
6SL3211-1NE23-8UG1
6SL3211-1NE23-8AG1
LO base load power 18.5 kW
LO base load input current 39.2 A
LO base load output current 38 A
HO base load power 15 kW
HO base load input current 33.1 A
HO base load output current 32 A
Fuse according to IEC / UL
Fuse according to UL, Class J
3NE1817-0
50 A
Power loss 0.45 kW
Required cooling air flow 18.5 l/s
Weight without filter 5.4 kg
Weight with filter 6 kg
Table 7-10 PM230, IP20, frame size D, 3 AC 380 V … 480 V
Article no. - without filter
Article no. - with filter
6SL3210-1NE24-5UL0
6SL3210-1NE24-5AL0
6SL3210-1NE26-0UL0
6SL3210-1NE26-0AL0
LO base load power 22 kW 30 kW
LO base load input current 42 A 56 A
LO base load output current 45 A 60 A
HO base load power 18.5 kW 22 kW
HO base load input current 36 A 42 A
HO base load output current 38 A 45 A
Fuse according to IEC / UL 3NE1818-0 3NE1820-0
Power loss 0.52 kW 0.68 kW
Required cooling air flow 80 l/s 80 l/s
Weight without filter 11 kg 11 kg
Weight with filter 14 kg 14 kg
Technical specifications
7.6 Detailed technical data
Power Module PM230, IP20 / Push-through technology (PT)
Hardware Installation Manual, 08/2016, A5E34331322B AB 67
