7.5 General technical data

Property Version

Line voltage 3 AC 380 V … 480 V ± 10 %

Output voltage 3 AC 0 V … input voltage x 0.95 (max.)

Input frequency 50 Hz … 60 Hz, ± 3 Hz

Output frequency 0 Hz ... 550 Hz, depending on the control mode

Power factor λ 0.9 for U

= 1 %

Inrush current < LO base load input current

Overvoltage category ac‐

cording to EN 60664‑1

Overvoltage category III for industrial line supplies

Short-circuit current rating

(SCCR)

65 kA rms with fuses, Class J or 3NE, rated voltage 600 V AC with the rated inverter current.

Line impedance Uk < 1 %, a line reactor is not permitted

Pulse frequency 4 kHz (factory setting),

Can be set in 2 kHz steps in the range 2 kHz … 16 kHz.

If you increase the pulse frequency, the inverter reduces the maximum output current.

Current reduction depending on pulse frequency (Page 70)

Note: The specified EMC properties are only valid for the pulse frequencies set in the factory.

Electromagnetic compatibili‐

The devices are suitable for environments of category C2 according to IEC/EN 61800-3. De‐

tails:

Restrictions for special ambient conditions (Page 69)

Braking methods DC braking, compound braking

Degree of protection accord‐

ing to EN 60529

Chassis devices

PT devices

IP20

IP20,

IP55

Must be installed in a control cabinet

at the control cabinet panel

Technical specifications

7.5 General technical data

Power Module PM230, IP20 / Push-through technology (PT)
