8.3 Optional accessories
8.3.1 Mounting frames for Power Module with push-through technology
Order numbers for mounting frames
● FSA: 6SL3260-6AA00-0DA0
● FSB: 6SL3260-6AB00-0DA0
● FSC: 6SL3260-6AC00-0DA0
All of the necessary nuts and seals are included in the scope of delivery.
Mounting instructions for the mounting frames
Procedure
Proceed as follows to correctly mount the Power Module:
1. Prepare a cutout and holes in the control cabinet panel for the mounting frame
corresponding to the dimension drawing.
2. Insert the mounting frame from the rear of the control cabinet through the corresponding
holes and fix it in place at the fixing screws for the control cabinet panel; tighten the two
nuts by hand.
3. Attach the seal to the inner side of the control cabinet.
4. Insert the Power Module and tighten the screws by hand.
5. Finally, tighten the eight or ten screws with a torque of 3.5 Nm.
You have correctly installed the Power Module.
