8.3.5 Shield connection kit
The shield connection kit is used to connect the shield of the control and motor cables in an
EMC-compliant fashion.
● The shield plate is included in the scope of delivery of Power Modules, frame sizes FSA …
FSC.
● For frame sizes FSD … FSF, the shield connection kit can be ordered as option under the
following article numbers.
– FSD: 6SL3262-1AD00-0DA0
– FSE: 6SL3262-1AD00-0DA0
– FSF: 6SL3262-1AF00-0DA0
The mounting instructions for the shield connection kits, frame sizes FSD … FSF are available
in the Internet at (https://support.industry.siemens.com/cs/ww/de/view/23621093/en):
Spare parts and accessories
8.3 Optional accessories
Power Module PM230, IP20 / Push-through technology (PT)
88 Hardware Installation Manual, 08/2016, A5E34331322B AB
