Installation Instructions

Technical data
7.6 Specific technical data
PM230 Power Module, IP55
54 Hardware Installation Manual, 12/2016, A5E35319202B AB
Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE23-0AG1
6SL3223-0DE23-0BG1
LO base load power
3 kW
LO base load input current
8.0 A
LO base load output current
7.7 A
HO base load power
2.2 kW
HO base load input current
6.1 A
HO base load output current
5.9 A
Fuse according to IEC
Fuse according to UL, class J
3NA3803
10 A
Power loss
0.12 kW
Required cooling air flow
7 l/s
Weight
4.3 kg
Table 7- 4 PM230, IP55, frame size B, 380 V … 480 V 3 AC
Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE24-0AG1
6SL3223-0DE24-0BG1
6SL3223-0DE25-5AG1
6SL3223-0DE25-5BG1
6SL3223-0DE27-5AG1
6SL3223-0DE27-5BG1
LO base load power
4 kW
5.5 kW
7.5 kW
LO base load input current
10.5 A
13.6 A
18.6 A
LO base load output current
10.2 A
13.2 A
18 A
HO base load power
3 kW
4 kW
5.5 kW
HO base load input current
8.0 A
10.5 A
13.6 A
HO base load output current
7.7 A
10.2 A
13.2 A
Fuse according to IEC
Fuse according to UL, class J
3NA3805
16 A
3NA3807
25 A
3NA3810
35 A
Power loss
0.14 kW
0.18 kW
0.24 kW
Required cooling air flow
9 l/s
9 l/s
9 l/s
Weight
6.3 kg
6.3 kg
6.3 kg
