Technical data
7.5 General technical data
PM230 Power Module, IP55
52 Hardware Installation Manual, 12/2016, A5E35319202B AB
7.5
General technical data
Feature
Version
Mains voltage
380 … 480 V 3 AC ± 10%
Output voltage
0 V 3 AC … input voltage x 0.95 (max.)
Input frequency
50 Hz … 60 Hz, ± 3 Hz
Output frequency
0 Hz … 550 Hz, depending on the control mode
Power factor λ
0.9
Line impedance
Uk ≤ 1%, no line reactor permitted
Starting current
Low LO base load input current
Pulse frequency (factory
setting)
4 kHz
The pulse frequency can be increased in 2 kHz steps up to 16 kHz (up to 8 kHz for 75 kW
and 90 kW). An increase in the pulse frequency results in a lower output current.
Braking methods
DC braking
Degree of protection IP55 To comply with this degree of protection requires the following:
• Operation with operator panel or dummy cover
• Connections for control cables are made properly using EMC cable glands.
Establishing a line and motor connection (Page 34)
Rated short-circuit current When fused using a type J or 3NE1 fuse, rated voltage 480 VAC
with the rated current of the specific inverter.
FSA ... FSC: 40 kA
FSD ... FSF: 65 kA
