Technical data
7.4 Ambient conditions
PM230 Power Module, IP55
Hardware Installation Manual, 12/2016, A5E35319202B AB
51
7.4
Ambient conditions
Property
Version
Ambient conditions for transport in the transport packaging
Climatic ambient conditions
- 25 °C … + 55 °C, Class 1K3 according to EN 60721-3-1
Mechanical ambient condi-
tions
Shock and vibration permissible, Class 2M3 according to EN 60721-3-2
Protection against chemical
substances
Protected according to Class 2C2 to EN 60721-3-2
Biological environmental
conditions
Suitable according to Class 2B1 to EN 60721-3-2
Ambient conditions for long-term storage in the product packaging
Climatic ambient conditions - 40 °C … + 70 °C, Class 2K4 according to EN 60721-3-2
Maximum humidity 95% at 40 °C
Mechanical ambient condi-
tions
Shock and vibration permissible, Class 1M2 according to EN 60721-3-1
Protection against chemical
substances
Protected according to Class 1C2 to EN 60721-3-1
Biological environmental
conditions
Suitable according to Class 1B1 according to EN 60721-3-1
Ambient conditions in operation
Installation altitude
Up to 1,000 m above sea level without derating,
> 1,000 m Restrictions for special ambient conditions (Page 57)
Climatic ambient conditions
1)
• Temperature range without derating
2)
– LO base load power: -10 °C ... 40 °C
– HO base load power: -10 °C ... 50 °C
For higher temperatures.
Restrictions for special ambient conditions (Page 57)
• Relative humidity: 5 … 95%, condensation not permitted
• Oil mist, salt mist, ice formation, condensation, dripping water, spraying water, splashing
water and water jets are not permitted
Mechanical ambient condi-
tions
Shock and vibration permissible, Class 3M2 according to EN 60721-3-3
Protection against chemical
substances
Protected acc. to Class 3C2 to EN 60721-3-3
Biological environmental
conditions
Suitable for Class 3B1 according to EN 60721-3-3
Pollution Suitable for environments with degree of pollution 2 according to EN 61800-5-1
Protected from contact with dangerous parts, dust, spray water and water jets
Cooling
Forced air cooling AF, according to EN 60146
Cooling air
Clean and dry air
1)
Increased ruggedness regarding temperature range and relative humidity; therefore better than Class 3K3 to EN 60721-
3-3
2)
Observe the permissible ambient temperatures for the Control Unit and possibly the operator panel (IOP or BOP-2).
