Connecting
5.3 Connecting the line and motor cable at the inverter
PM230 Power Module, IP55
Hardware Installation Manual, 12/2016, A5E35319202B AB
39
Furthermore, you must use EMC cable glands for the motor connection and connections of
the Control Unit.
Establishing a line and motor connection (Page 34)
Table 5- 2 Permissible cable lengths
Cable length
Inverter, motor cable
EMC
25 m
• Inverters with Category C2 filters
• Shielded motor cable
First Environment, Category C2
• Inverters with Category C1 filters
• Shielded motor cable
First Environment, Category C1 (in relation
to the harmonic currents)
*)
50 m
• Inverters with Category C2 filters
• Shielded motor cable
Second Environment, Category C3
• Inverters with Category C1 filters
• Shielded motor cable
Second Environment, Category C2
Valid for FSA … FSC
100 m
• Inverters with Category C2 filters
• Unshielded motor cable
No EMC category
• Inverters with Category C1 filters
• UNshielded motor cable
No EMC category
*)
Ferrite cores required
Need for ferrites (Page 34)
