Technical data

7.6 Specific technical data

PM230 Power Module, IP55

56 Hardware Installation Manual, 12/2016, A5E35319202B AB

Table 7- 7 PM230, IP55, frame size E, 380 V … 480 V 3 AC

Article No. with filter, C2

Article No. with filter, C1

6SL3223-0DE33-7AG0

6SL3223-0DE33-7BG0

6SL3223-0DE34-5AG0

6SL3223-0DE34-5BG0

LO base load power

37 kW

45 kW

LO base load input current

70 A

84 A

LO base load output current

75 A

90 A

HO base load power

30 kW

37 kW

HO base load input current

56 A

70 A

HO base load output current

60 A

75 A

Fuse according to IEC

Fuse according to UL, class J

3NA3830

100 A

3NA3832

125 A

Power loss

0.99 kW

1.2 kW

Required cooling air flow rate

39 l/s

Weight

35.8 kg

Table 7- 8 PM230, IP55, frame size F, 380 V … 480 V 3 AC

Article No. with filter, C2

Article No. with filter, C1

6SL3223-0DE35-5AG0

6SL3223-0DE35-5BG0

6SL3223-0DE37-5AG0

6SL3223-0DE37-5BG0

6SL3223-0DE38-8AG0

6SL3223-0DE38-8BG0

LO base load power

55 kW

75 kW

90 kW

LO base load input current

102 A

135 A

166 A

LO base load output current

110 A

145 A

178 A

HO base load power

45 kW

55 kW

75 kW

HO base load input current

84 A

102 A

135 A

HO base load output current

90 A

110 A

145 A

Fuse according to IEC

Fuse according to UL, class J

3NA3836

160 A

3NA3140

200 A

3NA3144

250 A

Power loss

1.4 kW

1.9 kW

2.3 kW

Required cooling air flow

117 l/s

Weight

70.0 kg
