Installation Instructions

● EMC installation guideline (http://support.automation.siemens.com/WW/view/en/
60612658)
EMC-compliant control cabinet design, potential equalization and cable routing
● Accessories manual (https://support.industry.siemens.com/cs/ww/en/ps/13225/man)
Installation descriptions for inverter components, e.g. line reactors and line filters. The
printed installation descriptions are supplied together with the components.
A.1.2 Configuring support
Catalog
Ordering data and technical information for SINAMICS G inverters.
Catalog D31 for download or online catalog (Industry Mall):
All about SINAMICS G120 (www.siemens.com/sinamics-g120)
SIZER
The configuration tool for SINAMICS, MICROMASTER and DYNAVERT T drives, motor
starters, as well as SINUMERIK, SIMOTION controllers and SIMATIC technology
SIZER on DVD:
Article number: 6SL3070-0AA00-0AG0
Download SIZER (http://support.automation.siemens.com/WW/view/en/10804987/130000)
EMC (electromagnetic compatibility) technical overview
Standards and guidelines, EMC-compliant control cabinet design
EMC overview (https://support.industry.siemens.com/cs/ww/en/view/103704610)
EMC Guidelines configuration manual
EMC-compliant control cabinet design, potential equalization and cable routing
EMC installation guideline (http://support.automation.siemens.com/WW/view/en/60612658)
