Installation Instructions

Table 7-11 PM230, IP20, frame size E, 3 AC 380 V … 480 V
Article no. - without filter
Article no. - with filter
6SL3210-1NE27-5UL0
6SL3210-1NE27-5AL0
6SL3210-1NE28-8UL0
6SL3210-1NE28-8AL0
LO base load power 37 kW 45 kW
LO base load input current 70 A 84 A
LO base load output current 75 A 90 A
HO base load power 30 kW 37 kW
HO base load input current 56 A 70 A
HO base load output current 60 A 75 A
Fuse according to IEC / UL 3NE1021-0 3NE1022-0
Power loss 0.99 kW 1.2 kW
Required cooling air flow 80 l/s 80 l/s
Weight without filter 15 kg 15 kg
Weight with filter 22 kg 22 kg
Table 7-12 PM230, IP20, frame size F, 3 AC 380 V … 480 V
Article no. - without filter
Article no. - with filter
6SL3210-1NE31-1UL0
6SL3210-1NE31-1AL0
6SL3210-1NE31-5UL0
6SL3210-1NE31-5AL0
LO base load power 55 kW 75 kW
LO base load input current 102 A 135 A
LO base load output current 110 A 145 A
HO base load power 45 kW 55 kW
HO base load input current 84 A 102 A
HO base load output current 90 A 110 A
Fuse according to IEC / UL 3NE1224-0 3NE1225-0
Power loss 1.4 kW 1.9 kW
Required cooling air flow 150 l/s 150 l/s
Weight without filter 33 kg 33 kg
Weight with filter 48 kg 48 kg
Technical specifications
7.6 Detailed technical data
Power Module PM230, IP20 / Push-through technology (PT)
68 Hardware Installation Manual, 08/2016, A5E34331322B AB
