Table 8-4 Dimensions and weights
Article number Overall dimensions (mm) Drilling dimen‐
sions (mm)
Fixing/torque
(Nm)
Weight
(kg)
W H D b t
6SL3202-0AE16-1CA0 207 166 73 166 57 4 x M4 / 3 Nm 3.4
6SL3202-0AE18-8CA0 207 166 73 166 57 4 x M4 / 3 Nm 3.9
6SL3202-0AE21-8CA0 247 211 100 225 81 4 x M5 / 6 Nm 10.1
6SL3202-0AE23-8CA0 257 228 115 225 85 4 x M5 / 6 Nm 11.2
Assignment table
Power Module Output reactor
Article number Power Frame size Article number
6SL3210-1NE11-3 . G1
6SL3210-1NE11-7 . G1
6SL3210-1NE12-2 . G1
6SL3210-1NE13-1 . G1
6SL3210-1NE14-1 . G1
6SL3210-1NE15-8 . G1
0.37 kW
0.55 kW
0.75 kW
1.1 kW
1.5 kW
2.2 kW
FSA 6SL3202-0AE16-1CA0
6SL321 . -1NE17-7 . G1 3 kW
6SL3210-1NE21-0 . G1
6SL3210-1NE21-3 . G1
6SL321 . -1NE21-8 . G1
4 kW
5.5 kW
7.5 kW
FSB 6SL3202-0AE18-8CA0
6SL3210-1NE22-6 . G1
6SL3210-1NE23-2 . G1
6SL321 . 0-1NE23-8 . G1
11 kW
15 kW
18.5 kW
FSC 6SL3202-0AE21-8CA0
