Installation Instructions

Technical data
Article number Power
loss (W)
at 50 Hz
Connection (mm
2
) De‐
gree
of pro‐
tec‐
tion
Line supply PE Power Module
6SL3203-0BE17-7BA0 13 Screw terminals
2.5 mm
2
M5 studs Integrated,
450 mm
IP20
6SL3203-0BE21-8BA0 22 6 mm
2
screw ter‐
minals
M5 studs Integrated,
500 mm
IP20
6SL3203-0BE23-8BA0 49 16 mm
2
screw
terminals
M6 studs Integrated,
540 mm
IP20
6SL3203-0BE27-5BA0 Screw terminals
16 … 50 mm
2
M6 studs integrated, 1 m IP20
6SL3203-0BE31-1BA0 Screw terminals
16 … 50 mm
2
M6 studs integrated, 1 m IP20
6SL3203-0BE31-8BA0 Screw terminals
35 … 150 mm
2
M10 studs integrated, 1.1 m IP20
Assignment table
Power Module Line filter
Article number Frame
size
Article number Catego‐
ry
6SL3210-1NE11-3UG1 6SL3210-1NE11-7UG1
6SL3210-1NE12-2UG1 6SL3210-1NE13-1UG1
6SL3210-1NE14-1UG1 6SL3210-1NE15-8UG1
6SL321 . -1NE17-7UG1
FSA 6SL3203-0BE17-7BA0 C1
6SL3210-1NE21-0UG1 6SL3210-1NE21-3UG1
6SL321 . -1NE21-8UG1
FSB 6SL3203-0BE21-8BA0 C1
6SL3210-1NE22-6UG1 6SL3210-1NE23-2UG1
6SL321 . -1NE23-8UG1
FSC 6SL3203-0BE23-8BA0 C1
6SL3210-1NE24-5UL0 6SL3210-1NE26-0UL0 FSD 6SL3203-0BE27-5BA0 C1
6SL3210- 1NE27-5UL0 6SL3210- 1NE28-8UL0 FSE 6SL3203-0BE31-1BA0 C1
6SL3210-1NE31-1UL0 6SL3210-1NE31-5UL0 FSF 6SL3203-0BE31-8BA0 C1
. : Stands for 1 or 2:
1: Built-in device
2: Push-through device
8.3.3 Sine-wave filter
The sine-wave filter at the inverter output limits the voltage rate-of-rise and the peak voltages
at the motor winding. The maximum permissible length of motor feeder cables is increased to
300 m.
Spare parts and accessories
8.3 Optional accessories
Power Module PM230, IP20 / Push-through technology (PT)
82 Hardware Installation Manual, 08/2016, A5E34331322B AB
