PM230 Power Module, IP55
Hardware Installation Manual, 12/2016, A5E35319202B AB
17
Launch
3
Overview
The PM230 Power Modules belong to the modular family of SINAMICS G120 inverters. A
modular inverter comprises Control Unit and Power Module.
PM230 Power Modules have been specifically designed for pump and fan drives in industrial
HVAC applications for a mains voltage range of 3 AC 380 V … 480 V.
They are available with a category C1 or C2 filter in the following frame sizes:
•
FSA
C1
C2
0.37
kW … 3 kW
•
FSB
C1
C2
4
kW … 7.5 kW
•
FSC
C1
11
kW … 15 kW
•
FSC
C2
11 kW
… 18.5
•
FSD
C1
18.5
kW … 30 kW
•
FSD
C2
22
kW … 30 kW
•
FSE
C1
C2
37
kW … 45 kW
•
FSF
C1
C2
55
kW … 90 kW
The specified power ratings refer to Low Overload operation.
Control Units for the Power Modules
You can operate the Power Modules with a Control Unit from one of the following listed
families from firmware version 4.4 and higher.
● CU230P-2
● CU240B-2
● CU240E-2
Operation with Control Units other than those listed above is not permitted.
Note
Commissioning the inverter
You must first commission the inverter before you can use it. Commissioning is described in
the operating instructions of the relevant Control Unit.
Manuals for your inverter (Page 67).
