Article no. - without filter
Article no. - with filter
6SL3210-1NE13-1UG1
6SL3210-1NE13-1AG1
6SL3210-1NE14-1UG1
6SL3210-1NE14-1AG1
6SL3210-1NE15-8UG1
6SL3210-1NE15-8AG1
Weight without filter 1.4 kg 1.4 kg 1.4 kg
Weight with filter 1.6 kg 1.6 kg 1.6 kg
Table 7-4 PM230, IP20, frame size A, 3 AC 380 V … 480 V
Article no. - without filter
Article no. - with filter
6SL3210-1NE17-7UG1
6SL3210-1NE17-7AG1
LO base load power 3 kW
LO base load input current 8.0 A
LO base load output current 7.7 A
HO base load power 2.2 kW
HO base load input current 6.1 A
HO base load output current 5.9 A
Fuse according to IEC / UL
Fuse according to UL, Class J
3NE1813-0
10 A
Circuit breaker N3RV2711-1KD10 12.5 A
Power loss 0.11 kW
Required cooling air flow 4.5 l/s
Weight without filter 1.4 kg
Weight with filter 1.6 kg
Table 7-5 PM230, PT, frame size A, 3 AC 380 V … 480 V
Article no. - without filter
Article no. - with filter
6SL3211-1NE17-7UG1
6SL3211-1NE17-7AG1
LO base load power 3 kW
LO base load input current 8.0 A
LO base load output current 7.7 A
HO base load power 2.2 kW
HO base load input current 6.1 A
HO base load output current 5.9 A
Fuse according to IEC / UL
Fuse according to UL, Class J
3NE1813-0
10 A
Power loss 0.11 kW
Required cooling air flow 4.5 l/s
Weight without filter 1.7 kg
Weight with filter 1.9 kg
Technical specifications
7.6 Detailed technical data
Power Module PM230, IP20 / Push-through technology (PT)
Hardware Installation Manual, 08/2016, A5E34331322B AB 65
