7.6 Detailed technical data
Note
Values for Low Overload and High Overload
The values for Low Overload (LO) are identical with those of the rated values.
Power loss of the Power Modules
The values specified for the power loss are typical values at 100% of the rated speed and
100% of the load corresponding to Low Overload.
Table 7-2 PM230, IP20, frame size A, 3 AC 380 V … 480 V
Article no. - without filter
Article no. - with filter
6SL3210-1NE11-3UG1
6SL3210-1NE11-3AG1
6SL3210-1NE11-7UG1
6SL3210-1NE11-7AG1
6SL3210-1NE12-2UG1
6SL3210-1NE12-2AG1
LO base load power 0.37 kW 0.55 kW 0.75 kW
LO base load input current 1.3 A 1.8 A 2.3 A
LO base load output current 1.3 A 1.7 A 2.2 A
HO base load power 0.25 kW 0.37 kW 0.55 kW
HO base load input current 0.9 A 1.3 A 1.8 A
HO base load output current 0.9 A 1.3 A 1.7 A
Fuse according to IEC / UL
Fuse according to UL, Class J
3NE1813-0
2 A
3NE1813-0
4 A
3NE1813-0
4 A
Circuit breaker 3RV2711-1KD10 12.5 A 12.5 A 12.5 A
Power loss 0.04 kW 0.04 kW 0.05 kW
Required cooling air flow 1.5 l/s 1.5 l/s 4.5 l/s
Weight without filter 1.4 kg 1.4 kg 1.4 kg
Weight with filter 1.6 kg 1.6 kg 1.6 kg
Table 7-3 PM230, IP20, frame size A, 3 AC 380 V … 480 V
Article no. - without filter
Article no. - with filter
6SL3210-1NE13-1UG1
6SL3210-1NE13-1AG1
6SL3210-1NE14-1UG1
6SL3210-1NE14-1AG1
6SL3210-1NE15-8UG1
6SL3210-1NE15-8AG1
LO base load power 1.1 kW 1.5 kW 2.2 kW
LO base load input current 3.2 A 4.2 A 6.1 A
LO base load output current 3.1 A 4.1 A 5.9 A
HO base load power 0.75 kW 1.1 kW 1.5 kW
HO base load input current 2.3 A 3.2 A 4.2 A
HO base load output current 2.2 A 3.1 A 4.1 A
Fuse according to IEC / UL
Fuse according to UL, Class J
3NE1813-0
6 A
3NE1813-0
6 A
3NE1813-0
10 A
Power loss 0.06 kW 0.07 kW 0.08 kW
Circuit breaker N3RV2711-1KD10 12.5 A 12.5 A 12.5 A
Required cooling air flow 4.5 l/s 4.5 l/s 4.5 l/s
