7.3 Electromagnetic compatibility - overview
Electromagnetic compatibility according to EN61800-3
Property Version
Interference immunity The inverters are suitable for use in the first and second industrial environments
Interference emission -
second environment
Category C2 for inverters with integrated radio interference suppression filter
Category C2 for inverters without filter with optional external radio interference suppression
filter for grounded line supplies (recommended for operation in conjunction with
a residual current protective device RCD)
Category C3 for inverters with integrated radio interference suppression filter, format FSF
Category C4 for inverters without integrated radio interference suppression filter for opera‐
tion on IT line supplies
Additional information as well as conditions for using the inverter in the first environment are
provided in the following Section:
Electromagnetic compatibility of variable-speed drives (Page 71).
