Operation Manual
Table Of Contents
- EH9..SV...
- Ú Table of contents[en] Instruction manual
- : Safety precautions
- Please read this manual carefully. Please keep the instruction and installation manual as well as the appliance certificate in a safe place for later use or for subsequent owners.
- Check the appliance after removing it from the packaging. If it has suffered any damage in transport, do not connect the appliance, contact the Technical Assistance Service and provide written notification of the damage caused, otherwise you will los...
- This appliance must be installed according to the installation instructions included.
- This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
- Do not use lids or unsuitable child safety grilles. These can cause accidents, due to overheating, catching fire or materials shattering, for example.
- This appliance is not intended for operation with an external clock timer or a remote control.
- This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...
- Children must not play with the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
- Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
- Risk of fire!
- ■ Hot oil and fat can ignite very quickly. Never leave hot fat or oil unattended. Never use water to put out burning oil or fat. Switch off the hotplate. Extinguish flames carefully using a lid, fire blanket or something similar.
- ■ The hotplates become very hot. Never place combustible items on the hob. Never place objects on the hob.
- ■ The appliance gets hot. Do not keep combustible objects or aerosol cans in drawers directly underneath the hob.
- ■ The hob switches off automatically and can no longer be operated. It may switch on unintentionally at a later point. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- Risk of burns!
- ■ The hotplates and surrounding area (particularly the hob surround, if fitted) become very hot. Never touch the hot surfaces. Keep children at a safe distance.
- ■ The hotplate heats up but the display does not work. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- ■ Metal objects on the hob quickly become very hot. Never place metal objects (such as knives, forks, spoons and lids) on the hob.
- ■ After each use, always turn off the hob at the main switch. Do not wait until the hob turns off automatically after the pan is removed.
- Risk of electric shock!
- ■ Incorrect repairs are dangerous. Repairs may only be carried out and damaged power cables replaced by one of our trained after-sales technicians. If the appliance is defective, unplug the appliance from the mains or switch off the circuit breaker...
- ■ Penetrating moisture may cause an electric shock. Do not use any high- pressure cleaners or steam cleaners.
- ■ A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.
- ■ Cracks or fractures in the glass ceramic may cause electric shocks. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- Electromagnetic hazards!
- Malfunction risk!
- The hob is equipped with a fan in the lower section. If there is a drawer under the hob it should not be used to store small objects or paper, since they could damage the fan or interfere with the cooling if they are sucked into it.
- There should be a minimum of 2 cm between the contents of the drawer and fan intake.
- Risk of injury!
- ■ When cooking in a bain marie, the hob and cooking container could shatter due to overheating. The cooking container in the bain marie must not directly touch the bottom of the water-filled pot. Only use heat-resistant cookware.
- ■ Saucepans may suddenly jump due to liquid between the pan base and the hotplate. Always keep the hotplate and saucepan bases dry.
- Overview
- Ferromagnetic cookware
- Other cookware for induction
- Unsuitable pans
- Characteristics of the pan base
- Absence of pan or unsuitable size
- Empty pans or those with a thin base
- Pan detection
- Control panels
- Selecting the hotplate and the power level
- Changing the power level
- Switch off the hotplate
- How to activate
- How to activate
- 1. Place the pan and select the desired hotplate by pressing its programming zone.
- 2. Press the þ symbol. The þ indicator lights up.
- 3. Now select the desired power level by sliding your finger over the corresponding programming zone for one of the two hotplates that form part of the flexible hotplate.
- Changing the power level
- Adding more cookware
- To deactivate
- Return to using two hotplates
- Activating and deactivating
- Automatic programming
- Changing or cancelling the time
- Once the time has elapsed
- How to program
- Changing or cancelling the time
- Once the time has elapsed
- Quit
- Cleaning
- : Safety precautions
9
Flexible hotplate
It may be used as one complete hotplate or two individual
hotplates depending on the cooking needs at the moment.
It is made up of 4 inductors which work independently. When
the flexible hotplate is working, only the hotplate covered by the
pan is activated.
Note: The centre hotplate is made up of 3 inductors, working
as one complete hotplate.
Advice on using cookware
To ensure that the cookware is detected and heat is distributed
evenly, correctly centre the cookware:
Warnings
When using cookware of a different size or made of a different
material, noise and vibrations that do not affect the correct
working of the zone may occur.
Consisting of two independent zones
The flexible zone can be used normally as two independent
hotplates.
How to activate
See “adjusting the hotplate“ section.
As one hotplate
To use the entire hotplate with all individual zones.
How to activate
The hob must be switched on.
1. Place the pan and select the desired hotplate by pressing its
programming zone.
2. Press the þ symbol. The þ indicator lights up.
The flexible zone has been activated.
3. Now select the desired power level by sliding your finger over
the corresponding programming zone for one of the two
hotplates that form part of the flexible hotplate.
The power level lights up on the indicators for both hotplates.
The flexible zone is switched on.
Changing the power level
Change the power level by sliding your finger over one of the
two programming zones.
Adding more cookware
Press the
þ symbol. The ê indicator lights up during the
search and detection of new cookware. The new pan will be
detected and the previously selected power level will be
maintained.
Note: If the pan on the hotplate that is switched on is moved or
removed, the hob will perform an automatic search and the
previously selected power level will be maintained.
To deactivate
Set it to
‹ in the programming zone.
Return to using two hotplates
Select one of the two hotplates of the flexible zone and set to
‹.
Note: When a hob is switched off and later switched on again,
the flexible zone will again be used as two hotplates.
As one hotplate
Diameter less than or equal to 13 cm
Place the cookware on one of the four posi-
tions shown in the image.
Diameter greater than 13 cm
Place the cookware on one of the three
positions shown in the image.
If the cookware takes up more than one hot-
plate, place it at the top or bottom edge of
the flexible zone.
As two independent hotplates
The front and back hotplates, each with two
inductors, can be used independently by
selecting the necessary power for each
one. In this case, it is recommended to only
use one pan on each hotplate.
Central hotplate
Diameter less than or equal to 13 cm
Place the pan in one of the three positions
shown in the diagram.
Diameter greater than 13 cm
Place the pan in one of the two positions
shown in the diagram.
If the pan covers more than two inductors,
place it on the upper or lower edge of the
hotplate.
To obtain maximum power with the
Powerboost Function, place the
cookware in the centre of the flexi-
ble zone when used as a single hot-
plate.
On hobs with more than one flexible
zone, it is not recommended to use
several zones at the same time for a
single pan.
