Operation Manual
Table Of Contents
- EH9..SV...
- Ú Table of contents[en] Instruction manual
- : Safety precautions
- Please read this manual carefully. Please keep the instruction and installation manual as well as the appliance certificate in a safe place for later use or for subsequent owners.
- Check the appliance after removing it from the packaging. If it has suffered any damage in transport, do not connect the appliance, contact the Technical Assistance Service and provide written notification of the damage caused, otherwise you will los...
- This appliance must be installed according to the installation instructions included.
- This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
- Do not use lids or unsuitable child safety grilles. These can cause accidents, due to overheating, catching fire or materials shattering, for example.
- This appliance is not intended for operation with an external clock timer or a remote control.
- This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...
- Children must not play with the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
- Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
- Risk of fire!
- ■ Hot oil and fat can ignite very quickly. Never leave hot fat or oil unattended. Never use water to put out burning oil or fat. Switch off the hotplate. Extinguish flames carefully using a lid, fire blanket or something similar.
- ■ The hotplates become very hot. Never place combustible items on the hob. Never place objects on the hob.
- ■ The appliance gets hot. Do not keep combustible objects or aerosol cans in drawers directly underneath the hob.
- ■ The hob switches off automatically and can no longer be operated. It may switch on unintentionally at a later point. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- Risk of burns!
- ■ The hotplates and surrounding area (particularly the hob surround, if fitted) become very hot. Never touch the hot surfaces. Keep children at a safe distance.
- ■ The hotplate heats up but the display does not work. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- ■ Metal objects on the hob quickly become very hot. Never place metal objects (such as knives, forks, spoons and lids) on the hob.
- ■ After each use, always turn off the hob at the main switch. Do not wait until the hob turns off automatically after the pan is removed.
- Risk of electric shock!
- ■ Incorrect repairs are dangerous. Repairs may only be carried out and damaged power cables replaced by one of our trained after-sales technicians. If the appliance is defective, unplug the appliance from the mains or switch off the circuit breaker...
- ■ Penetrating moisture may cause an electric shock. Do not use any high- pressure cleaners or steam cleaners.
- ■ A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.
- ■ Cracks or fractures in the glass ceramic may cause electric shocks. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- Electromagnetic hazards!
- Malfunction risk!
- The hob is equipped with a fan in the lower section. If there is a drawer under the hob it should not be used to store small objects or paper, since they could damage the fan or interfere with the cooling if they are sucked into it.
- There should be a minimum of 2 cm between the contents of the drawer and fan intake.
- Risk of injury!
- ■ When cooking in a bain marie, the hob and cooking container could shatter due to overheating. The cooking container in the bain marie must not directly touch the bottom of the water-filled pot. Only use heat-resistant cookware.
- ■ Saucepans may suddenly jump due to liquid between the pan base and the hotplate. Always keep the hotplate and saucepan bases dry.
- Overview
- Ferromagnetic cookware
- Other cookware for induction
- Unsuitable pans
- Characteristics of the pan base
- Absence of pan or unsuitable size
- Empty pans or those with a thin base
- Pan detection
- Control panels
- Selecting the hotplate and the power level
- Changing the power level
- Switch off the hotplate
- How to activate
- How to activate
- 1. Place the pan and select the desired hotplate by pressing its programming zone.
- 2. Press the þ symbol. The þ indicator lights up.
- 3. Now select the desired power level by sliding your finger over the corresponding programming zone for one of the two hotplates that form part of the flexible hotplate.
- Changing the power level
- Adding more cookware
- To deactivate
- Return to using two hotplates
- Activating and deactivating
- Automatic programming
- Changing or cancelling the time
- Once the time has elapsed
- How to program
- Changing or cancelling the time
- Once the time has elapsed
- Quit
- Cleaning
- : Safety precautions
13
Fixing malfunctions
Malfunctions are usually due to small details. Before calling the
Technical Assistance Service, you should consider the
following advice and warnings.
Normal noise while the appliance is working
Induction heating technology is based on the creation of
electromagnetic fields that generate heat directly at the base of
the pan. Depending on how the pan has been manufactured,
certain noises or vibrations may be produced such as those
described below:
A deep humming sound as in a transformer
This noise is produced when cooking with a high power level. It
is caused by the amount of energy transferred from the hob to
the pan. The noise disappears or becomes faint when the
power level is lowered.
A low whistling sound
This noise is produced when the pan is empty. The noise
disappears when water or food is added to the pan.
A crackling sound
This noise occurs in pans which are made from different
materials superimposed on one another. It is caused by the
vibrations that occur in the adjoining surfaces of the different
superimposed materials. The noise comes from the pan. The
amount of food and cooking method can vary noise intensity.
A high-pitched whistling sound
This noise is produced mainly in pans made from different
materials superimposed on one another, and it occurs when
such pans are heated at maximum power on two hotplates at
the same time. The whistling disappears or becomes fainter as
soon as the power level is lowered.
Noise from the fan
For proper use of the electronic system, the temperature of the
hob must be controlled. To do this, the hob has a fan which
turns on when a high temperature is detected. The fan may also
work by inertia after the hob has been switched off, if the
temperature detected is still too high.
The noises described are normal, they are part of induction
heating technology and not a sign of malfunction.
Indicator Malfunction Solution
none The electric power supply has been cut off. Use other electrical appliances to check whether there has been a
power cut.
The appliance has not been correctly con-
nected following the connection diagram.
Check that the appliance has been connected correctly according to
the connection diagram.
Electronic system malfunction. If in the above checks, the malfunction is not resolved, contact the
Technical Assistance Service.
“ flashes
The control panel is damp or an object is
resting on it.
Dry the control panel area or remove the object.
Ҥ + number /
š + number /
¡ + number
Electronic system malfunction. Unplug the hob from the mains. Wait about 30 seconds before plug-
ging it in again.*
”‹
There is an internal error in the operation. Unplug the hob from the mains. Wait about 30 seconds before plug-
ging it in again.*
”ƒ
The electronic system has overheated and
the corresponding hotplate has been
switched off.
Wait until the electronic system has cooled down completely. Then
push any symbol on the hob.*
”…
The electronic system has overheated and
all hotplates have been switched off.
—‚
Supply voltage outside normal operating
limits.
Please contact the local electricity board.
—ƒ / —„
The hotplate has overheated and has
switched off in order to protect its cooking
surface.
Wait until the electronic system has cooled down sufficiently before
switching it back on.
* If the warning persists call the Technical Assistance Service.
Do not rest hot pans on the control panel.
