Operation Manual
Table Of Contents
- EH...FE...
- Ú Table of contents[en] Instruction manual
- : Safety precautions
- Please read this manual carefully. Please keep the instruction and installation manual as well as the appliance certificate in a safe place for later use or for subsequent owners.
- Check the appliance after removing it from the packaging. If it has suffered any damage in transport, do not connect the appliance, contact the Technical Assistance Service and provide written notification of the damage caused, otherwise you will los...
- This appliance must be installed according to the installation instructions included.
- This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
- Do not use lids or unsuitable child safety grilles. These can cause accidents, due to overheating, catching fire or materials shattering, for example.
- This appliance is not intended for operation with an external clock timer or a remote control.
- This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...
- Children must not play with the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
- Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
- Risk of fire!
- ■ Hot oil and fat can ignite very quickly. Never leave hot fat or oil unattended. Never use water to put out burning oil or fat. Switch off the hotplate. Extinguish flames carefully using a lid, fire blanket or something similar.
- ■ The hotplates become very hot. Never place combustible items on the hob. Never place objects on the hob.
- ■ The appliance gets hot. Do not keep combustible objects or aerosol cans in drawers directly underneath the hob.
- ■ The hob switches off automatically and can no longer be operated. It may switch on unintentionally at a later point. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- Risk of burns!
- ■ The hotplates and surrounding area (particularly the hob surround, if fitted) become very hot. Never touch the hot surfaces. Keep children at a safe distance.
- ■ The hotplate heats up but the display does not work. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- ■ Metal objects on the hob quickly become very hot. Never place metal objects (such as knives, forks, spoons and lids) on the hob.
- ■ After each use, always turn off the hob at the main switch. Do not wait until the hob turns off automatically after the pan is removed.
- Risk of electric shock!
- ■ Incorrect repairs are dangerous. Repairs may only be carried out and damaged power cables replaced by one of our trained after-sales technicians. If the appliance is defective, unplug the appliance from the mains or switch off the circuit breaker...
- ■ Penetrating moisture may cause an electric shock. Do not use any high- pressure cleaners or steam cleaners.
- ■ A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.
- ■ Cracks or fractures in the glass ceramic may cause electric shocks. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- Electromagnetic hazards!
- Malfunction risk!
- The hob is equipped with a fan in the lower section. If there is a drawer under the hob it should not be used to store small objects or paper, since they could damage the fan or interfere with the cooling if they are sucked into it.
- There should be a minimum of 2 cm between the contents of the drawer and fan intake.
- Risk of injury!
- ■ When cooking in a bain marie, the hob and cooking container could shatter due to overheating. The cooking container in the bain marie must not directly touch the bottom of the water-filled pot. Only use heat-resistant cookware.
- ■ Saucepans may suddenly jump due to liquid between the pan base and the hotplate. Always keep the hotplate and saucepan bases dry.
- Overview
- Protecting the environment
- Unpack the appliance and dispose of its packaging in such a way that no damage is caused to the environment.
- Environmentally-friendly disposal
- Energy-saving advice
- ■ Always use the correct lid for each pan. Cooking without a lid uses a lot more energy. Use a glass lid to provide visibility and avoid having to lift the lid.
- ■ Use pans with flat bases. Bases that are not flat use a lot more energy.
- ■ The diameter of the pan base must match the size of the hotplate. If the diameter is too small compared to the hotplate, energy can be wasted. Please note: pan manufacturers usually provide the diameter for the top of the pan, which is usually la...
- ■ Use a small pan for small amounts of food. A large pan which is not full uses a lot of energy.
- ■ Use little water when cooking. This saves energy and preserves all the vitamins and minerals in vegetables.
- ■ Always cover as much of the hotplate as possible with the pan.
- Induction cooking
- Protecting the environment
- Ferromagnetic cookware
- Other cookware for induction
- Unsuitable pans
- Characteristics of the pan base
- Absence of pan or unsuitable size
- Empty pans or those with a thin base
- Pan detection
- Control panels
- Selecting the hotplate and the power level
- Changing the power level
- Switch off the hotplate
- Select the hotplate and set it to ‹ in the programming panel. The hotplate turns off and the residual heat indicator appears.
- Notes
- Cooking guidelines table
- Frying function
- ■ Only use oil which is suitable for frying. If using butter, margarine, olive oil or pork lard, select the min temperature setting.
- 2. Within the next 10 seconds, select the desired temperature setting in the programming zone.
- 3. After reaching the temperature setting, add oil to the pan and then the ingredients.
- Turning off the deep-frying function
- Activating and deactivating
- All of the relevant information on the automatic childproof lock connection can be found in the Basic settings chapter.
- Powerboost function
- 2. Press the › symbol.
- 2. Press the › symbol.
- 3. Within the next 10 seconds, select the desired cooking time in the programming zone. The possible default setting is, from left to right: 1, 2, 3, etc., up to 10 minutes.
- Automatic programming
- Changing or cancelling the time
- Automatically switch off a hotplate with the deep-frying function
- Once the time has elapsed
- Programming
- Changing or cancelling the time
- Once the time has elapsed
- When the 0 symbol is pressed, the indicators turn off and the beeping stops.
- Cleaning lock function
- Automatic time limitation
- Displaying energy consumption
- Basic settings
- 2. Within the next 10 seconds, press and hold the ' symbol for 4 seconds.
- 4. Then select the desired setting with the programming zone.
- Quit
- Cleaning
- ■ Undiluted washing-up liquid
- ■ Dishwasher detergent
- ■ Abrasive products
- ■ Corrosive products such as oven sprays or stain removers
- ■ Sponges that may scratch
- Suitable glass scrapers can be obtained through the Technical Assistance Service or from our online shop.
- Hob frame
- Fixing malfunctions
- After-sales service
- Tested dishes
- : Safety precautions
6
Unsuitable pans
Never use diffuser hobs or pans made from:
■ common thin steel
■ glass
■ earthenware
■ copper
■ aluminium
Characteristics of the pan base
The characteristics of the pan base may affect the uniformity of
the cooking results. Pans made from materials which help
diffuse heat, such as stainless steel sandwich pans, distribute
heat uniformly, saving time and energy.
Absence of pan or unsuitable size
If no pan is placed on the selected hotplate, or if it is made of
unsuitable material or is not the correct size, the power level
displayed on the hotplate indicator will flash. Place a suitable
pan on the hotplate to stop the flashing. If this takes more than
90 seconds, the hotplate will switch off automatically.
Empty pans or those with a thin base
Do not heat empty pans, nor use pans with a thin base. The
hob is equipped with an internal safety system. However, an
empty pan may heat up so quickly that the "automatic switch
off" function may not have time to react and the pan may reach
very high temperatures. The base of the pan could melt and
damage the glass on the hob. In this case, do not touch the
pan and switch the hotplate off. If it fails to work after it has
cooled down, please contact the Technical Assistance Service.
Pan detection
Each hotplate has a minimum limit for detecting pans, which
varies depending on the material of the pan being used. You
should therefore use the hotplate that is most suitable for the
diameter of your pan.
Getting to know your appliance
The instruction manual is the same for various different hobs.
An overview of the models with their dimensions is given on
page 2.
The control panel
Control panels
Pressing a symbol activates its corresponding function.
Note: Always keep the control surfaces dry. Moisture can affect
proper working.
The hotplates
Control panels
#
Main switch
¹
Selecting the hotplate
0 IIIIIIIIIIII + Programming zone
&
Powerboost Function
0
Timer programming
‚
Childproof lock
$
Cleaning lock function
~
Frying Function
Indicators
‚-Š
Power levels
‹
Functionality
‹‹
Time program function
•/œ
Residual heat
›
Powerboost Function
V
Timer
x
Automatic shut-off
‘
Frying Function
p
Frying Function Temperature
min, low, med, max Temperature settings
Hotplate Turning on and off
$
Single hotplate Always use cookware of a suitable size.
Use only cookware suitable for induction cooking; see the section on suitable cookware.
