Operation Manual
Table Of Contents
- EH...FE...
- Ú Table of contents[en] Instruction manual
- : Safety precautions
- Please read this manual carefully. Please keep the instruction and installation manual as well as the appliance certificate in a safe place for later use or for subsequent owners.
- Check the appliance after removing it from the packaging. If it has suffered any damage in transport, do not connect the appliance, contact the Technical Assistance Service and provide written notification of the damage caused, otherwise you will los...
- This appliance must be installed according to the installation instructions included.
- This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
- Do not use lids or unsuitable child safety grilles. These can cause accidents, due to overheating, catching fire or materials shattering, for example.
- This appliance is not intended for operation with an external clock timer or a remote control.
- This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...
- Children must not play with the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
- Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
- Risk of fire!
- ■ Hot oil and fat can ignite very quickly. Never leave hot fat or oil unattended. Never use water to put out burning oil or fat. Switch off the hotplate. Extinguish flames carefully using a lid, fire blanket or something similar.
- ■ The hotplates become very hot. Never place combustible items on the hob. Never place objects on the hob.
- ■ The appliance gets hot. Do not keep combustible objects or aerosol cans in drawers directly underneath the hob.
- ■ The hob switches off automatically and can no longer be operated. It may switch on unintentionally at a later point. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- Risk of burns!
- ■ The hotplates and surrounding area (particularly the hob surround, if fitted) become very hot. Never touch the hot surfaces. Keep children at a safe distance.
- ■ The hotplate heats up but the display does not work. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- ■ Metal objects on the hob quickly become very hot. Never place metal objects (such as knives, forks, spoons and lids) on the hob.
- ■ After each use, always turn off the hob at the main switch. Do not wait until the hob turns off automatically after the pan is removed.
- Risk of electric shock!
- ■ Incorrect repairs are dangerous. Repairs may only be carried out and damaged power cables replaced by one of our trained after-sales technicians. If the appliance is defective, unplug the appliance from the mains or switch off the circuit breaker...
- ■ Penetrating moisture may cause an electric shock. Do not use any high- pressure cleaners or steam cleaners.
- ■ A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.
- ■ Cracks or fractures in the glass ceramic may cause electric shocks. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- Electromagnetic hazards!
- Malfunction risk!
- The hob is equipped with a fan in the lower section. If there is a drawer under the hob it should not be used to store small objects or paper, since they could damage the fan or interfere with the cooling if they are sucked into it.
- There should be a minimum of 2 cm between the contents of the drawer and fan intake.
- Risk of injury!
- ■ When cooking in a bain marie, the hob and cooking container could shatter due to overheating. The cooking container in the bain marie must not directly touch the bottom of the water-filled pot. Only use heat-resistant cookware.
- ■ Saucepans may suddenly jump due to liquid between the pan base and the hotplate. Always keep the hotplate and saucepan bases dry.
- Overview
- Protecting the environment
- Unpack the appliance and dispose of its packaging in such a way that no damage is caused to the environment.
- Environmentally-friendly disposal
- Energy-saving advice
- ■ Always use the correct lid for each pan. Cooking without a lid uses a lot more energy. Use a glass lid to provide visibility and avoid having to lift the lid.
- ■ Use pans with flat bases. Bases that are not flat use a lot more energy.
- ■ The diameter of the pan base must match the size of the hotplate. If the diameter is too small compared to the hotplate, energy can be wasted. Please note: pan manufacturers usually provide the diameter for the top of the pan, which is usually la...
- ■ Use a small pan for small amounts of food. A large pan which is not full uses a lot of energy.
- ■ Use little water when cooking. This saves energy and preserves all the vitamins and minerals in vegetables.
- ■ Always cover as much of the hotplate as possible with the pan.
- Induction cooking
- Protecting the environment
- Ferromagnetic cookware
- Other cookware for induction
- Unsuitable pans
- Characteristics of the pan base
- Absence of pan or unsuitable size
- Empty pans or those with a thin base
- Pan detection
- Control panels
- Selecting the hotplate and the power level
- Changing the power level
- Switch off the hotplate
- Select the hotplate and set it to ‹ in the programming panel. The hotplate turns off and the residual heat indicator appears.
- Notes
- Cooking guidelines table
- Frying function
- ■ Only use oil which is suitable for frying. If using butter, margarine, olive oil or pork lard, select the min temperature setting.
- 2. Within the next 10 seconds, select the desired temperature setting in the programming zone.
- 3. After reaching the temperature setting, add oil to the pan and then the ingredients.
- Turning off the deep-frying function
- Activating and deactivating
- All of the relevant information on the automatic childproof lock connection can be found in the Basic settings chapter.
- Powerboost function
- 2. Press the › symbol.
- 2. Press the › symbol.
- 3. Within the next 10 seconds, select the desired cooking time in the programming zone. The possible default setting is, from left to right: 1, 2, 3, etc., up to 10 minutes.
- Automatic programming
- Changing or cancelling the time
- Automatically switch off a hotplate with the deep-frying function
- Once the time has elapsed
- Programming
- Changing or cancelling the time
- Once the time has elapsed
- When the 0 symbol is pressed, the indicators turn off and the beeping stops.
- Cleaning lock function
- Automatic time limitation
- Displaying energy consumption
- Basic settings
- 2. Within the next 10 seconds, press and hold the ' symbol for 4 seconds.
- 4. Then select the desired setting with the programming zone.
- Quit
- Cleaning
- ■ Undiluted washing-up liquid
- ■ Dishwasher detergent
- ■ Abrasive products
- ■ Corrosive products such as oven sprays or stain removers
- ■ Sponges that may scratch
- Suitable glass scrapers can be obtained through the Technical Assistance Service or from our online shop.
- Hob frame
- Fixing malfunctions
- After-sales service
- Tested dishes
- : Safety precautions
5
Overview
The following table presents the most common damage
caused:
Protecting the environment
Unpack the appliance and dispose of its packaging in such a
way that no damage is caused to the environment.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly manner.
Energy-saving advice
■ Always use the correct lid for each pan. Cooking without a lid
uses a lot more energy. Use a glass lid to provide visibility
and avoid having to lift the lid.
■ Use pans with flat bases. Bases that are not flat use a lot
more energy.
■ The diameter of the pan base must match the size of the
hotplate. If the diameter is too small compared to the
hotplate, energy can be wasted. Please note: pan
manufacturers usually provide the diameter for the top of the
pan, which is usually larger than the diameter of the pan
base.
■ Use a small pan for small amounts of food. A large pan which
is not full uses a lot of energy.
■ Use little water when cooking. This saves energy and
preserves all the vitamins and minerals in vegetables.
■ Always cover as much of the hotplate as possible with the
pan.
■ Select the lowest power level to maintain cooking. If the
power level is too high, energy is wasted.
Induction cooking
Advantages of induction cooking
Induction cooking represents a radical change from the
traditional method of heating; the heat is generated directly in
the pan. It therefore offers a number of advantages:
■ Time savings for cooking and frying; since the pan is heated
directly.
■ Energy is saved.
■ Care and cleaning are simpler. Foods that have spilt do not
burn as quickly.
■ Heat and safety control; the hob supplies or cuts off power as
soon as the control knob is turned on. The induction hotplate
stops supplying heat if the pan is removed without having
previously switched it off.
Suitable pans
Ferromagnetic cookware
Only ferromagnetic cookware is suitable for induction cooking,
these may be made from:
■ enamelled steel
■ cast iron
■ special cutlery for stainless steel induction pan.
To determine whether a pan is suitable, check to see if a
magnet will stick to it.
Other cookware for induction
There are other types of cookware especially made for
induction cooking whose base is not entirely ferromagnetic.
Damage Cause Measure
Stains Food spillage Immediately remove spilt food using a glass scraper.
Unsuitable cleaning products Only use cleaning products specifically designed for glass-ceramic hobs.
Scratches Salt, sugar and sand Do not use the hob as a tray or working surface.
Pans with rough bottoms may scratch
the glass ceramic
Check pans.
Fading Unsuitable cleaning products Only use cleaning products specifically produced for glass-ceramic hobs.
Contact with pans Lift pots and pans before moving them around.
Chips Sugar, substances with a high sugar
content
Immediately remove spilt food using a glass scraper.
This appliance is labelled in accordance with European
Directive 2012/19/EU concerning used electrical and
electronic appliances (waste electrical and electronic
equipment - WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.
When using large cookware on a
smaller ferromagnetic area, only
the ferromagnetic zone heats up,
so heat might not be uniformly
distributed.
Pans with aluminium areas
inserted in the base reduce the
ferromagnetic area, so less heat
may be supplied and the pan
may be difficult to detect or not
be detected at all.
For good cooking results, the
diameter of the cookware's ferro-
magnetic area should match the
size of the hotplate. If cookware
is not detected on a hotplate, try
it on the next smaller hotplate
down.
