Operation Manual
Table Of Contents
- EH...FE...
- Ú Table of contents[en] Instruction manual
- : Safety precautions
- Please read this manual carefully. Please keep the instruction and installation manual as well as the appliance certificate in a safe place for later use or for subsequent owners.
- Check the appliance after removing it from the packaging. If it has suffered any damage in transport, do not connect the appliance, contact the Technical Assistance Service and provide written notification of the damage caused, otherwise you will los...
- This appliance must be installed according to the installation instructions included.
- This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
- Do not use lids or unsuitable child safety grilles. These can cause accidents, due to overheating, catching fire or materials shattering, for example.
- This appliance is not intended for operation with an external clock timer or a remote control.
- This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...
- Children must not play with the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
- Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
- Risk of fire!
- ■ Hot oil and fat can ignite very quickly. Never leave hot fat or oil unattended. Never use water to put out burning oil or fat. Switch off the hotplate. Extinguish flames carefully using a lid, fire blanket or something similar.
- ■ The hotplates become very hot. Never place combustible items on the hob. Never place objects on the hob.
- ■ The appliance gets hot. Do not keep combustible objects or aerosol cans in drawers directly underneath the hob.
- ■ The hob switches off automatically and can no longer be operated. It may switch on unintentionally at a later point. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- Risk of burns!
- ■ The hotplates and surrounding area (particularly the hob surround, if fitted) become very hot. Never touch the hot surfaces. Keep children at a safe distance.
- ■ The hotplate heats up but the display does not work. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- ■ Metal objects on the hob quickly become very hot. Never place metal objects (such as knives, forks, spoons and lids) on the hob.
- ■ After each use, always turn off the hob at the main switch. Do not wait until the hob turns off automatically after the pan is removed.
- Risk of electric shock!
- ■ Incorrect repairs are dangerous. Repairs may only be carried out and damaged power cables replaced by one of our trained after-sales technicians. If the appliance is defective, unplug the appliance from the mains or switch off the circuit breaker...
- ■ Penetrating moisture may cause an electric shock. Do not use any high- pressure cleaners or steam cleaners.
- ■ A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.
- ■ Cracks or fractures in the glass ceramic may cause electric shocks. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
- Electromagnetic hazards!
- Malfunction risk!
- The hob is equipped with a fan in the lower section. If there is a drawer under the hob it should not be used to store small objects or paper, since they could damage the fan or interfere with the cooling if they are sucked into it.
- There should be a minimum of 2 cm between the contents of the drawer and fan intake.
- Risk of injury!
- ■ When cooking in a bain marie, the hob and cooking container could shatter due to overheating. The cooking container in the bain marie must not directly touch the bottom of the water-filled pot. Only use heat-resistant cookware.
- ■ Saucepans may suddenly jump due to liquid between the pan base and the hotplate. Always keep the hotplate and saucepan bases dry.
- Overview
- Protecting the environment
- Unpack the appliance and dispose of its packaging in such a way that no damage is caused to the environment.
- Environmentally-friendly disposal
- Energy-saving advice
- ■ Always use the correct lid for each pan. Cooking without a lid uses a lot more energy. Use a glass lid to provide visibility and avoid having to lift the lid.
- ■ Use pans with flat bases. Bases that are not flat use a lot more energy.
- ■ The diameter of the pan base must match the size of the hotplate. If the diameter is too small compared to the hotplate, energy can be wasted. Please note: pan manufacturers usually provide the diameter for the top of the pan, which is usually la...
- ■ Use a small pan for small amounts of food. A large pan which is not full uses a lot of energy.
- ■ Use little water when cooking. This saves energy and preserves all the vitamins and minerals in vegetables.
- ■ Always cover as much of the hotplate as possible with the pan.
- Induction cooking
- Protecting the environment
- Ferromagnetic cookware
- Other cookware for induction
- Unsuitable pans
- Characteristics of the pan base
- Absence of pan or unsuitable size
- Empty pans or those with a thin base
- Pan detection
- Control panels
- Selecting the hotplate and the power level
- Changing the power level
- Switch off the hotplate
- Select the hotplate and set it to ‹ in the programming panel. The hotplate turns off and the residual heat indicator appears.
- Notes
- Cooking guidelines table
- Frying function
- ■ Only use oil which is suitable for frying. If using butter, margarine, olive oil or pork lard, select the min temperature setting.
- 2. Within the next 10 seconds, select the desired temperature setting in the programming zone.
- 3. After reaching the temperature setting, add oil to the pan and then the ingredients.
- Turning off the deep-frying function
- Activating and deactivating
- All of the relevant information on the automatic childproof lock connection can be found in the Basic settings chapter.
- Powerboost function
- 2. Press the › symbol.
- 2. Press the › symbol.
- 3. Within the next 10 seconds, select the desired cooking time in the programming zone. The possible default setting is, from left to right: 1, 2, 3, etc., up to 10 minutes.
- Automatic programming
- Changing or cancelling the time
- Automatically switch off a hotplate with the deep-frying function
- Once the time has elapsed
- Programming
- Changing or cancelling the time
- Once the time has elapsed
- When the 0 symbol is pressed, the indicators turn off and the beeping stops.
- Cleaning lock function
- Automatic time limitation
- Displaying energy consumption
- Basic settings
- 2. Within the next 10 seconds, press and hold the ' symbol for 4 seconds.
- 4. Then select the desired setting with the programming zone.
- Quit
- Cleaning
- ■ Undiluted washing-up liquid
- ■ Dishwasher detergent
- ■ Abrasive products
- ■ Corrosive products such as oven sprays or stain removers
- ■ Sponges that may scratch
- Suitable glass scrapers can be obtained through the Technical Assistance Service or from our online shop.
- Hob frame
- Fixing malfunctions
- After-sales service
- Tested dishes
- : Safety precautions
12
Automatic programming
If the previous setting from 1 to 5 is pressed in the
programming zone, the cooking time is reduced by one minute.
If the previous setting from 6 to 10 is pressed in the
programming zone, the cooking time is increased by one
minute.
Changing or cancelling the time
Select the hotplate and then press the
0 symbol.
Change the cooking time using the programming zone or set
to
‹‹ in order to cancel the time.
Automatically switch off a hotplate with the deep-frying
function
When cooking using the deep-frying function, the programmed
cooking time begins to count down once the selected zone
reaches the desired temperature.
Once the time has elapsed
The hotplate switches off. A warning signal sounds. The time
program function lights up
‹‹ for 10 seconds in the display.
When the
0 symbol is pressed, the indications turn off and the
beeping stops.
Notes
■ If cooking times have been programmed for various
hotplates, the time programming function always displays the
time for the selected hotplate.
■ Any cooking time can be programmed for up to 99 minutes.
The timer
The timer can be set for periods of up to 99 minutes. It is
independent of the other settings. This function does not
automatically switch off a hotplate.
Programming
1.Press the 0 symbol several times until the W indicator lights
up.
‹‹ lights up in the time program function display.
2.Select the desired time in the programming panel.
The timer starts to count down after a few seconds.
Changing or cancelling the time
Press the
0 symbol several times until the W indicator lights
up. Change the time with the programming zone, or set to
‹‹.
Once the time has elapsed
A warning signal sounds. In the time program function
display
‹‹ is shown, and the W indicator lights up. After
10 seconds the indicators turn off.
When the
0 symbol is pressed, the indicators turn off and the
beeping stops.
Cleaning lock function
Cleaning the control panel while the hob is switched on may
change the settings.
In order to avoid this, the hob has a cleaning lock function.
Press the ‚/$symbol. A signal sounds. The control panel is
locked for 35 seconds. The control panel surface can now be
cleaned without the risk of changing the settings.
Note: The lock does not affect the main switch. The hob may
be turned off when desired.
Automatic time limitation
If the hotplate remains in use for a long time and no changes
are made in the settings, the automatic time limitation function
is triggered.
The hotplate stops heating. The
”, ‰ symbol and the residual
heat indicator
œ/• flash alternately in the display.
The indicator goes out when any symbol is pressed. The
hotplate can now be reset.
When the automatic time function is used, it is governed by the
selected power level (from 1 to 10 hours).
Displaying energy consumption
This function displays total energy consumption for the time the
hob has been switched on.
After switching off the hob, the consumption in kWh is
displayed for 10 seconds.
An example is shown in the image with a consumption
of
‚.‹‰ kWh.
The Basic Settings chapter provides information on activating
this function.
