Product and service data sheet

Remote Access Desigo

Type 1: Manually renewable subscription

The service remotely accesses Cloud-enabled devices for a fleet of connected sites.

● Remote tool access with ABT Site to Desigo PXC4.E16 and PXC5.E003 automa-

tion stations

● Remote web access to Desigo PXC4.E16 and PXC5.E003 web interface

● Remote access to local web applications within the connected buildings

● Collects and downloads Intelligent Valve data

● Updates firmware and conducts HVAC balancing self-tests for Intelligent Valves

A6V12046495_en--_c

Smart Infrastructure

2021-03-31

Summary of content (6 pages)

PAGE 1
Product and service data sheet Remote Access Desigo Type 1: Manually renewable subscription The service remotely accesses Cloud-enabled devices for a fleet of connected sites. ● ● ● ● ● A6V12046495_en--_c 2021-03-31 Remote tool access with ABT Site to Desigo PXC4.E16 and PXC5.E003 automation stations Remote web access to Desigo PXC4.E16 and PXC5.
PAGE 2
Functions URL https://assets.bpcloudapps.siemens.com Asset management Adds and edits your sites and Cloud-enabled connected devices. Remote web access Remotely accesses the device web interface. Desigo engineering tool access - ABT Site Connects ABT Site (V4.0 or higher) to Desigo PXC4.E16 and PXC5.E003 automation stations and remotely engineers and configures the automation stations.
PAGE 3
Free trial Standard and the Master Order Form Subscription term 6 months, one-time 1 year Billing term n/a Annually, upfront Renewable No Yes Standard n/a Not included Not included Upgradeable Hardware Prerequisites Contractual documents Your company must sign a Master Order Form for Digital Services with your local Siemens entity to use the service.
PAGE 4
Ordering Order number Article type Description Free trail P55811-Y111-A100 CLD.RA.TRL Remote tool and web access to 1 site with up to 10 devices; free trial for 6 months Standard service P55811-Y110-A100 CLD.RA.STD Remote tool and web access to 1 site with up to 10 devices; subscription for 1 year Connect X300 gateway S55842-Z121-A100 CXG3.X300 Connect X300 for web access to 1 site with up to 10 devices Automation station S55375-C100 PXC4.
PAGE 5
Technical documents Document ID Connect X300 data sheet A6V11473182 Connect X300 quick install guide A6V11508811 Desigo™ automation station PXC4.E16 A6V11646018 Desigo™ automation station PXC5.E003 A6V11646020 Remote access Desigo engineering document A6V12096474 ABT Site A6V10431913 Intelligent Valve engineering guide A6V11999683 Intelligent Valve – BACnet objects A6V11757108 Technical documents can be downloaded at the following Internet address: http://siemens.
PAGE 6
Specific terms Terms of use for the Cloud-enabled devices at the connected site You are solely responsible for the correct configuration, security and use of the hardware device after installation at the connected site, ensuring that the hardware device can connect with the service and that the content, integrity, security, and accuracy of the data being transferred is correct, up-to-date, and regularly monitored.
