General Description

Desigo CC™ Compact for Building Automation (BA) offers full integration of building

automation, while also supporting in the southbound open standards such as BACnet, OPC,

Modbus, and many more. Options are available for dedicated, browser-based, and Windows

desktop app clients using the same user interface. Additionally, web interfaces provide

increased flexibility for operation and future extensions such as mobile applications for

tablets and smartphones.

System Architecture

Desigo CC™ Compact BA is a single-station system designed to augment existing building

infrastructure and integrate with standard IT hardware, software, and networks. The open,

adaptable architecture can support virtual IT environments and advanced networks.

System Capabilities

● Multi-language support

● Web and remote access from mobile clients

● Open-data libraries designed for extensions and integrations

● Support for BACnet, OPC, Modbus, HTTP(S), M-bus, KNX, S7, HTML5

● Powerful features such as advanced event management, Mobile App, remote

notifications, reports, log viewer, scheduling, long-term storage, user management

● Consistent user interface concept across all applications, with graphic-oriented operation

workflows

● Online graphics engineering, including data discovery

● Support for Siemens and third-party building automation and other integrated systems

● Southbound open interfaces and SDK to develop subsystem extensions

● Consolidated Ecosystem program and network to share and expand subsystem

extensions, applications, utilities, and tools

Certifications and Approvals

Desigo CC™ Compact BA has been tested against a wide range of domain- and country-

specific norms and standards, including:

● BACnet Revision 1.15, certified by BACnet Testing Laboratory as BACnet Advanced

Workstation Software (BTL B-AWS)

● IT security compliant with the ISA-99/IEC 62443 Security Level: SL1

● OPC DA V2.05a and V3.0 Server, certified by the OPC Foundation certification program
