Datasheet

● of the characteristic impedance at 3 MHz … 20
MHz
10%
Loop resistance per length / maximum 98mΩ/m
Shield resistance per length / maximum 14Ω/km
Insulation resistance coefficient 16000GΩ·m
Capacity per length / at 1 kHz 29pF/m
Operating voltage
● RMS value
80V
Mechanical data
Number of electrical cores 2
Design of the shield Overlapped aluminum-clad foil, sheathed in a braided screen of
tin-plated copper wires
Type of electrical connection / FastConnect No
Outer diameter
● of inner conductor
0.8mm
● of the wire insulation
2.56mm
● of the inner sheath of the cable
6mm
● of cable sheath
8mm
Symmetrical tolerance of the outer diameter / of
cable sheath
0.4mm
Material
● of the wire insulation
polyethylene (PE)
● of cable sheath
PUR (TPE-U)
Color
● of the insulation of data wires
red/green
● of cable sheath
Violet
Bending radius
● with single bend / minimum permissible
30mm
● with continuous bending
60mm
Number of bending cycles Not suitable for garland usage
Number of torsion cycles / with torsion by ± 180° on 1
m cable length
5000000
Tensile load / maximum 100N
Weight per length 65kg/km
Permitted ambient conditions
Ambient temperature
● during operation
-25...+75°C
● during storage
-40...+80°C
● during transport
-40...+80°C
● during installation
-25...+75°C
● Note
Electrical properties measured at 20 °C, tests according to DIN
47250 part 4 respectively DIN VDE 0472
6XV1830-0PH10 Subject to change without notice
