Data Sheet

● analog signal transmission

Product properties, functions, components / general

Number of channels 8

Design of cable Round cable

Wire length 1.5m

Number of poles 16

Number of conductors / of connecting cable 16

Conductor cross section / Rated value 0.14mm²

Color / of cable sheath Black

Outer diameter / of cable sheath 6.5mm

Material / of the connecting cable sheath PVC

Connector type IDC connector

Type of electrical connection / on enclosure Connector strip

Number of poles / at the 1st interface 16; cable side front connector module

Type of electrical connection / in the field Connector strip

Number of poles / at the 2nd interface 16; on the connection module

Certificate of suitability / cULus approval No

Equipment marking / acc. to DIN EN 81346-2 W

Net weight 0.15kg

last modified:

06/12/2019

6ES7923-0BB50-0CB0 Subject to change without notice
