Data Sheet

Data sheet 5TC8263
NV dimmer for R, L 6-120W magnetic transformers and LED lamps
with ON/OFF pushbutton/selector switch FM, 230V 50-60Hz Screw
terminals Claw or screw mounting
Model
Product brand name DELTA
Product designation LV dimmer
Design of the product Insert
Type of load inductive load
Type of composition basic element
Design of the operating mechanism rotary knob/button
Design of dimmer / Series dimmer No
General technical data
Operating apparent output / rated value 6...120V·A
Dim power / minimum 6V·A
Mounting type Claw and screw fixing
Surface processing other
Material other
Supply voltage
Operating voltage / Rated value 230V
5TC8263 Subject to change without notice
Page 1/
3
09/13/2019 © Copyright Siemens
