Data Sheet

Product component front ring Yes

Design of the front ring Standard

Material of the front ring Metal, high gloss

Color of the front ring silver

General technical data

Protection class IP IP66, IP67, IP69(IP69K)

● of the terminal

IP20

Degree of protection NEMA rating NEMA 1, 2, 3, 3R, 4, 4X, 12, 13

Shock resistance

● acc. to IEC 60068-2-27

Sinusoidal half-wave 50 g / 11 ms

Operating frequency maximum 18001/h

Mechanical service life (switching cycles)

● typical

300000

Reference code acc. to DIN EN 81346-2 S

Reference code acc. to DIN EN 61346-2 S

Ambient conditions

Ambient temperature

● during operation

-25...+70°C

● during storage

-40...+80°C

Environmental category during operation acc. to IEC

60721

3M6, 3S2, 3B2, 3C3, 3K6 (with relative air humidity of 10 ... 95 %)

Installation/ mounting/ dimensions

Height 29.5mm

Width 29.5mm

Shape of the installation opening round

Mounting diameter 22.3mm

Positive tolerance of installation diameter 0.4mm

Mounting height 51.7mm

Installation width 29.5mm

Installation depth 25.4mm

Certificates/approvals

3SU1050-4FF01-0AA0 Subject to change without notice
