Data Sheet
Data sheet 3SU1050-4FF01-0AA0
Key-operated switch O.M.R, 22 mm, round, metal, shiny, lock
number 73037, red, with 2 keys, 2 switch positions O-I, latching,
actuating angle 90°, 10:30h/13:30h, Key removal O
Product brand name SIRIUS ACT
Product designation Key-operated switches
Design of the product Actuating/signaling element
Product type designation 3SU1
Actuator
Manner of function of the actuating element latching, 90° (10:30 h/13:30 h)
Product extension optional Light source No
Color
● of the actuating element
red
Material of the actuating element metal
Shape of the actuating element Key
Outer diameter of the actuating element 29.5mm
Number of switching positions 2
Switch position for key distraction O
Actuating angle
● clockwise
90°
Lock make O.M.R.
Key number 73037
Front ring
3SU1050-4FF01-0AA0 Subject to change without notice
Page 1/
4
09/13/2019 © Copyright Siemens
