Data Sheet

Material of the front ring plastic

Color of the front ring black

General technical data

Protection class IP IP66, IP67, IP69(IP69K)

Degree of protection NEMA rating NEMA 1, 2, 3, 3R, 4, 4X, 12, 13

Shock resistance

● acc. to IEC 60068-2-27

Sinusoidal half-wave 50 g / 11 ms

● for railway applications acc. to DIN EN 61373

Category 1, Class B

Operating frequency maximum 36001/h

Mechanical service life (switching cycles)

● typical

3000000

Reference code acc. to DIN EN 81346-2 S

Reference code acc. to DIN EN 61346-2 S

Ambient conditions

Ambient temperature

● during operation

-25...+70°C

● during storage

-40...+80°C

Environmental category during operation acc. to IEC

60721

3M6, 3S2, 3B2, 3C3, 3K6 (with relative air humidity of 10 ... 95 %)

Installation/ mounting/ dimensions

Height 29.5mm

Width 29.5mm

Shape of the installation opening round

Mounting diameter 22.3mm

Positive tolerance of installation diameter 0.4mm

Mounting height 16.2mm

Installation width 29.5mm

Installation depth 24.3mm

Certificates/approvals

3SU1001-0BB30-0AA0 Subject to change without notice
