Data Sheet

Data sheet 3SU1001-0BB30-0AA0
Illuminated pushbutton, 22 mm, round, plastic, yellow, pushbutton,
raised momentary contact type
Product brand name SIRIUS ACT
Product designation Illuminated pushbuttons
Design of the product Actuating/signaling element
Product type designation 3SU1
Enclosure
Number of command points 1
Actuator
Design of the operating mechanism Raised button
Manner of function of the actuating element momentary contact type
Product extension optional Light source Yes
Color
● of the actuating element
yellow
Material of the actuating element plastic
Shape of the actuating element round
Outer diameter of the actuating element 29.5mm
Front ring
Product component front ring Yes
Design of the front ring Standard
3SU1001-0BB30-0AA0 Subject to change without notice
Page 1/
4
09/13/2019 © Copyright Siemens
