Data sheet 3SU1000-1HF20-0AA0
EM. STOP MUSHROOM PUSHBUTTON, 22MM, ROUND,
PLASTIC, RED, 40MM, WITH RONIS LOCK, LOCK NO. SB30,
POSITIVE LATCHING, KEY-OPERATED RELEASE
product brand name SIRIUS ACT
Product designation Commanding and signaling devices
Design of the product Emergency stop mushroom pushbutton
Actuator:
Design of the operating mechanism Emergency stop mushroom pushbutton, tamper-proof
Manner of function of the actuating element Latching
Product expansion optional Light source No
Color
● of the actuating element
Red
Material of the actuating element plastic
Shape of the actuating element round
Outer diameter of the actuating element 40mm
Type of unlocking device Unlocking
Number of switching positions 2
Switch position for key distraction O
Lock make RONIS
Key number SB30
Front ring:
Product component front ring No
General technical data:
Product function
● positive opening
Yes
● EMERGENCY OFF function
Yes
● EMERGENCY STOP function
Yes
