Datasheet

— at 60 V rated value
A 3.5
— at 110 V rated value
A 1.3
— at 220 V rated value
A 0.9
— at 440 V rated value
A 0.2
— at 600 V rated value
A 0.1
● with 3 current paths in series at DC-13
— at 24 V rated value
A 10
— at 60 V rated value
A 4.7
— at 110 V rated value
A 3
— at 220 V rated value
A 1.2
— at 440 V rated value
A 0.5
— at 600 V rated value
A 0.26
Installation/ mounting/ dimensions:
Mounting type snap-on mounting
Width mm 23.6
Height mm 27.5
Depth mm 38.6
Connections/ Terminals:
Type of electrical connection for auxiliary and control
current circuit
screw-type terminals
Type of connectable conductor cross-sections
● for auxiliary contacts
— finely stranded
— with core end processing
2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²)
● at AWG conductors for auxiliary contacts
2x (20 ... 16), 2x (18 ... 14)
Safety related data:
Product function Mirror contact acc. to IEC 60947-4-1 Yes
● Note
with 3RT2
Product function positively driven operation acc. to
IEC 60947-5-1
Yes
● Note
with 3RH2
Certificates/ approvals:
3RH2911-1AA10 Changes preserved
Page 3/
5
17.03.2016 © Copyright Siemens AG
