HMI (Human-Machine Interface)
Push-button operation
Activity Push-button operation Confirmation
Enter / leave addressing mode Press button <1 s LED turns red or gets off
Reset to factory settings Press button >20 s LED flashes orange until device
restarts
PL-Link connection test
1)
Press key >2 s and <20 s LED flashes 1x orange
1)
Function or part of the function available in PL-Link operation only
LED colors and patterns
Color Pattern Description
Off --- Fault free operation or device not powered
Green steady Connection test successful
1)
Orange flashing
0.1 s on / 0.1 s off Factory reset in progress
0.25 s on / 1.75 s off When a connection test was triggered: wait
1)
Red
steady Device is in programming/addressing mode
flashing
0.5 s on / 2 s off Internal error: Power reset necessary
1 s on / 1 s off When a connection test was triggered: Connection test failed
1)
1)
Function or part of the function available in PL-Link operation only
Addressing and bus test with push button
The rotary actuators can be set into addressing/programming mode by push-button:
· Press push button (<1 s)
· KNX bus wiring OK à LED turns red until addressing/programming is finished
· KNX bus wiring not OK à LED stays dark
Reset with push button
The rotary actuators can be reset by push-button:
· Press push button >20 s
· LED flashes orange
· Device restarts
All parameters are reset to the default values.
