Controllers and room units Product no. Ordering no. Documentation
Room thermostat KNX RDG160KN S55770-T297 A6V10629627
(N3191)
Flush-mount room sensor KNX AQR2532NNW with
AQR2570NF or
AQR2576NF
S55720-S136
S55720-S203
S55720-S207
A6V10389050
(N1411)
Room control unit UP227/11 5WG1227-2AB11 A6V10387579
Software versions
G..B111.9E/KN series B are designed for using ETS device profile v2.x. ETS device profile
v1.x is supported for backward compatibility reasons.
Series information Series A Series B
Production period 12/2015 – 01/2017 01/2017
ETS device profile v1.x supported supported
ETS device profile v2.x not supported supported
Note: The Software-Tools ACS931 / 941 and the handheld tool AST20 are not supported by
the GDB111.9E/KN and GLB111.9E/KN.
Product documentation
Title Topic Document ID
Communication via the KNX bus Communication via the KNX bus A6V10075840 (P3127)
Mounting instruction Mounting instructions rotary actuator A6V10523083 (M4657)
or A6V10636144
Datasheet 6-port control ball valve Technical information on 6-port control ball valves
VWG41..
A6V10564480
Datasheet 2-port and 3-port control
ball valves, PN 40, with internally
threaded connection
Technical information on 2-port and 3-port control
ball valves VAI61… and VBI61..
N4211
Datasheet 2-port and 3-port control
ball valves, PN 40, with externally
threaded connection
Technical information on 2-port and 3-port control
ball valves VAG61… and VBG61..
N4212
Datasheet 2-port shutoff valves and
3-port changeover ball valves, PN
40, with internally threaded
connection
Technical information on 2-port shutoff and 3-port
changeover ball valves VAI60… and VBI60..
N4213
Datasheet 2-port shutoff valves and
3-port changeover ball valves, PN
40, with externally threaded
connection
Technical information on 2-port shutoff and 3-port
changeover ball valves VAG60… and VBG60..
N4114
How to obtain documentation and product-related software
Related documents such as environmental declarations, CE declarations, etc., can be down-
loaded at the following Internet address:
http://siemens.com/bt/download
The ETS device profile can be downloaded at the following Internet address:
http://siemens.com/hvac-td
