Functions
Function Description
Communication - KNX-TP, galvanically separated
- Max. 256 nodes per line (with repeaters)
- Busload 5 mA
Functions - Setpoint and actual value for actuator position 0..100%
- Operating mode “heating / cooling control” for 6-port control ball valve or
operating mode “position control” for 2-/3-port control ball valves
- Override control with binary communication objects
- Setpoint monitoring and backup mode
Type summary
Product no. Ordering no. Operating
voltage
Control signal Power
consumption
Running
time
Manual
override
Position
feedback
GDB111.9E/KN S55499-D203
AC 24 V KNX-TP
1 VA / 0.5 W
3 VA / 2.5 W
1)
150 s Yes Yes
GLB111.9E/KN S55499-D207
1)
Actuator rotates
Ordering information (example)
Product no. Ordering no. Description Volume
GDB111.9E/KN S55499-D203 Rotary actuator KNX for 6-port ball valve or
control ball valves
1
Equipment combinations
6-port control ball valves PN16 GDB..9E..
Medium: 5…90 °C G..B k
vs
[m
3
/h] DN ∆p
max
[kPa]
VWG41.10.. G ½ B 0.25 ..1.9 10 200
VWG41.20.. G 1 B 0.25 ..4.25 20 200
