Technical data
Power supply
Operating voltage G..B111.9E/KN AC 24 V ± 20% (SELV) or
AC 24 V class 2 (US)
Frequency 50/60 Hz
Power consumption at 50 Hz
Actuator holds 1 VA / 0.5 W
Actuator rotates 3 VA / 2.5 W
Function data
Positioning time for
nominal rotation angle
G..B111.9E/.. 150 s (50 Hz)
120 s (60 Hz)
Nominal torque GDB.. 5 Nm
GLB.. 10 Nm
Maximum torque GDB.. < 7 Nm
GLB.. < 14 Nm
Nominal / maximum
rotation angle
90° / 95° ± 2°
Direction of rotation Adjustable over bus (operating mode
“position control”)
Clockwise (CW) /
Counter-clockwise (CCW)
Connection cables
Cable length 0.9 m
Power supply Number of cores and cross-sectional area 2 x 0.75 mm
2
Communication Number of cores and cross-sectional area 2 x 0.75 mm
2
Communication
Communication protocol Connection type KNX-TP (el. isolated)
Bus load 5 mA
Degree of protection
Degree of protection Degree of protection acc. to EN 60529
(see mounting instruction)
IP54
Safety class Safety class acc. to EN 60730 III
Environmental conditions
Applicable standard IEC 60721-3-x
Operation Climatic conditions Class 3K5
Mounting location Indoors
Temperature general 0…50 °C
Humidity (noncondensing) 5…95 % r. F.
Transport Climatic conditions Class 2K3
Temperature -25…70 °C
Humidity 5...95 % r. h.
Storage Climatic conditions Class 1K3
Temperature -5…45 °C
Humidity 5...95 % r. h.
